Allen-Bradley 1336-Series
1336-Series Drive Control Logic Chart
Pocket Hardmount
WE-6 Control - Design 5 and Earlier
H – Signal Voltage High (approximately 5V DC)
L – Signal Voltage Low (less than 1V DC)
0 = No Signal Received
1 = Signal Received
SW2 SW1 SW3 Rev Stop Fwd
Input Status –
Parameter #55
DC Volt Meter Red Probe Terminal Location
27 28 26 22 20 19
DC Volt Meter Black Probe Terminal Location
29 29 29 29 29 29
Action
Frequency
Preset
Parameter #
Terminal
#27
(SW2)
Terminal
#28
(SW1)
Terminal
#26
(SW3)
Terminal
#22
(STR)
Terminal
#20
(Stop)
Terminal
#19
(STF)
SW2
SW1
SW3
Auxiliary
Rev (STR)
Not Used
Stop
Fwd (STF)
Idle
N/A H H H H L/H H 0001000/10
1/2 Wash Speed Forward
73 H H L H L L 00110011
1/2 Wash Speed Reverse
73 H H L L L H 00111010
Wash Speed Forward
28 L H H H L L 10010011
Wash Speed Reverse
28 L H H L L H 10011010
Distribution Speed
27 H L H H L L 01010011
Medium Extract/Spray Rinse
75 L H L H L L 10110011
High 1 Extract
74 H L L H L L 01110011
High 2 Extract
29 L L H H L L 11010011
High 3 Extract
76 L L L H L L 11110011
Pocket Hardmount
WE-6 Control Designs 6, 7 and 8
H – Signal Voltage High (approximately 5V DC)
L – Signal Voltage Low (less than 1V DC)
0 = No Signal Received
1 = Signal Received
SW2 SW1 SW3 Rev Stop Fwd
Input Status –
Parameter #55
DC Volt Meter Red Probe Terminal Location
27 28 26 22 20 19
DC Volt Meter Black Probe Terminal Location
29 29 29 29 29 29
Action
Frequency
Preset
Parameter #
Terminal
#27
(SW2)
Terminal
#28
(SW1)
Terminal
#26
(SW3)
Terminal
#22
(STR)
Terminal
#20
(Stop)
Terminal
#19
(STF)
SW2
SW1
SW3
Auxiliary
Rev (STR)
Not Used
Stop
Fwd (STF)
Idle
N/A H H H H L/H H 0001000/10
1/2 Wash Speed Forward
73 H H H H L L 00010011
1/2 Wash Speed Reverse
73 H H H L L H 00011010
Wash Speed Forward
28 L H H H L L 10010011
Wash Speed Reverse
28 L H H L L H 10011010
Distribution Speed
27 H L H H L L 01010011
Medium Extract/Spray Rinse
75 L H L H L L 10110011
High Extract Speed 1
74 H L L H L L 01110011
High Extract Speed 2
29 H L L L L H 00110011
High Extract Speed 3
(Default)
76 H H L H L L 11110011
High Extract Speed 3
(Maximum)
76 H H L H L L 00110011
Table 52
