Allen-Bradley 1305-Series AC Drives
69
F232120
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
1305-Series Drive Control Logic Chart
Cabinet Hardmount
V-Control and EDC/Netmaster Control
H – Control Voltage High (approximately 5V DC)
L – Control Voltage Low (less than 1V DC)
0 = No Signal Received
1 = Signal Received
SW3 SW2 SW1 Rev Stop Fwd
Input Status - Parameter #55
DC Volt Meter Red Probe Terminal Location
18 17 16 13 8 6
DC Volt Meter Black Probe Terminal Location
777777
Action
Frequency
Preset
Parameter
Terminal
#18
(SW3)
Terminal
#17
(SW2)
Terminal
#16
(SW1)
Terminal
#13
(STR)
Terminal
#8
(Stop)
Terminal
#6
(STF)
Not Used
SW3
SW2
SW1
Not Used
Rev (STR)
Stop
Fwd (STF)
Idle
N/A
HHHHL/HH0000000/10
1/2 Wash Speed Forward
27 H H L H L L 00010011
1/2 Wash Speed Reverse
27 H H L L L H 00010110
Wash Speed Forward
28 H L H H L L 00100011
Wash Speed Reverse
28 H L H L L H 00100110
Distribution Speed
73 L H H H L L 01000011
Spin 1
29 H L L H L L 00100011
Spin 2
75 L L H H L L 01100011
Spin 3
74 L H L H L L 01010011
Table 42
