Allen-Bradley 160-Series AC Drives
F232120
46
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
160 Series Drive Control Logic Chart
Pocket Hardmount - IPH, IP and CP Models
PS40 control
H – Control Voltage High (greater than 10V DC)
L – Control Voltage Low (less than 1V DC)
0 = No signal received
1 = Signal received
Fwd Stop Rev
Control Input Status –
Parameter 12
DC Volt Meter Red Probe Terminal Location
06 08 05
DC Volt Meter Black Probe Terminal Location
03 03 03
Action
Terminal
#06
(STF)
Terminal
#08
(Stop)
Terminal
#05
(STR)
Not Used
STF
Stop
STR
Idle
HLH0010
Wash Speed Forward
LL H0110
Wash Speed Reverse
HL L0011
Distribution Speed
LL H0110
Low Spin Speed
LLH0110
Medium Spin Speed
LLH0110
High Spin Speed
LLH0110
SmartSpin
LLL0111
NOTE: These models use analog signals to control speed – refer to parameter #6 (command freq.) and parameter #16 (analog
input %) to verify speed input signal.
Table 30
