PowerFlex 40 and 400 Drive Control Logic
F232120
26
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table 16 (continued)
PowerFlex 40
Parameter
Group and
Number
PowerFlex 400 Parameter Group
and Number
Parameter
Description
Function
d029 b013 Torque Current Displays the present value of the motor's
torque current (in Amps).
d030 N/A OL Level Displays the real-time motor overload
progression (100% = F007 Fault).
P041 P041 Reset to Defaults NOTE: This will reset the drive's
parameters back to the factory-default
values, requiring the AC drive to be re-
programmed. This will not reset A193.
(0 = Not Active; 1 = Reset - Induces
Fault F048).
A101 A198 Parameter Lock Allows parameter modification.
0 = Parameters Unlocked
1= Parameters Locked
See also parameters A192 and A193.
A152 N/A Limited
Frequency
Displays the maximum allowable
frequency (in Hz) based on DC Bus
voltage. The drive output frequency may
be limited due to low input voltage
conditions to alleviate potential motor
stalling.
A164 R261 Balance State Displays the balance detection algorithm
progression (See A187 and A188). (0 =
Algorithm not active; 1 = programmed
pause time; 2 = programmed sample
time; 3 = programmed filter time; 4 =
result obtained)
A187 N/A SmartSpin
Frequency
Displays the commanded SmartSpin
frequency (in Hz) as determined from
Balance Result A188.
A188 R285 Balance Result Displays the numeric value indicating
severity of load imbalance. A balance
result value will be displayed only when
A164 = 4, otherwise the display will be
0.
A192 N/A Parameter
CRC-16
Displays the numeric code culminating
from the value of all of the parameters.
This is intended as a quick reference and
is used to validate the parameter settings
for a specific application.
Table 16 (continued)
