Concurrent Multiple Video Outputs

72

• Directlypowercyclethedesireduserstation(s),beitanACTIVATOR

orFOLLOWERuserstation.

Note:IftheuserstationisP2‐USTIP,itautomaticallyentersthe

remotemodewhenquittingtheMultipleVideomode.Press

Ctrl+Alt+DeleteontheP2‐USTIPifyouwanttoreturntothelocal

mode.

Limitation

Thefunctionisnotapplicabletothosechannelswhichshareonlyone

pathviathetiereddevice,suchasP2ZCIM,P2CIM‐APS2‐Bor

P2CIM‐AUSB‐B(forIBMBladeCenterservers).

Messages on the ACTIVATOR User Station

Thesuccessand/orfailureofdataoutputsoftheFOLLOWERchannel(s)

willbedisplayedonthescreenoftheACTIVATORuserstation(seethe

exampleimagesbelow).



1

The1stFOLLOWERchannelsuccessfullyoutputsitsdata

2

The2ndFOLLOWERchannelsuccessfullyoutputsitsdata

3

The3rdFOLLOWERchannelCANNOTsuccessfullyoutputits

data

4

EveryFOLLOWERchannelsuccessfullyoutputsitsdata
