Chapter 7: Configurations

143

Non-Standard Tiered Configurations

Guidelines for Existing Firmware Versions

Non‐Standardtieredconfigurationsarethoseconfigurationssupported

byParagonII,butrequirespecialprocedureinordertofunctionproperly.

Theseinclude:

• TriangleConfiguration

• SingleDiamondConfiguration

• RedundantConfiguration

Recovery:

• Afteranyre‐connectionsubsequenttotheNon‐Standardtiered

configuration,allParagonswitchesshouldundergoaFUNCresetto

cleartheda

tabase.SeeʺResetUnitʺunderParagonIIFrontPanel

DisplayandControls(onpage16)formorein

formationonclearing

thedatabase.Thisprocedureshouldbeperformedstartingfromthe

third‐tierdevicedowntotheBaseUnit.

• Wheneverathird‐tierParagonswitchisreplaced,allofthe

second‐tierParagonswitchesandBaseUnitsshouldundergoa

FUNCreset.

• Wheneverasecond‐ti

erParagonswitchisreplaced,alloftheBase

UnitsshouldundergoaFUNCreset.

• Wheneverabase‐tierParagonswitch(BaseUnit)isreplaced,onlythe

newParagonswitchshouldundergoaFUNCreset.



Triangle Configuration

¾Thefollowingproceduremustbefollowedtoensurethisconfiguration

functionsproperly:

Afterre‐connection,allParagonswitchesmustundergoaFUNCresetto

cleartheswitchesʹdatabase.SeeʺResetUnitʺunderParagonIIFront

PanelDisplayandControls(onpage16)fo

rmoreinformationon

clearingthedatabase.Thisprocedureshouldbeperformedstartingfrom

thethird‐tierdevicedowntotheBaseUnit.

• ExecutetheFUNCresetinthefollowingorder:UMT‐3ÆUMT‐2Æ

UMT‐1.
