Chapter 7: Configurations

137

TheoperationisthesamefortiereddevicesthatarenotParagon

switches.



A

TiereddevicesthatarenotParagonswitches

B

Paragonswitches(UMT‐x)

C

Userstations

Guidelines for Multiple Base Configuration

Amultiplebaseconfigurationcouldbetwo‐tierorthree‐tier

configuration.ItiscomposedofmorethanoneParagonMainUnit,

servingasBaseUnits,andsecond‐tieroreventhird‐tierdevices.

Initialization

• Afteralldeviceshavebeenconnected,poweronthedevicesfrom

UPPERtiertolowertier.Fo

rexample,poweronthesecond‐tier

device(s)firstandthentheBaseUnitsinatwo‐tierconfiguration.

• Afterinitialization,eachtiereddevicehasanupdateddatabase.

Guidelinesforchangingconnectionsoftiereddevices:

ExampleA:Relocatingathird‐tierdevicewithmultiplesecond‐tierconnections

(refertore

dlineinthediagram):

1. Disconnectsomeoralloftheuserportsonanthird‐tierunit

(UMT‐3A)thatconnecttothechannelportsofsecond‐tierunits

(UMT‐2AandUMT‐2C)andre‐connecttheuserportstothechannel

portsofanothersecond‐tierun

it(UMT‐2B).
