Initial Configuration

22

Using the OSUI for Initial Configuration

YouwillusetheParagonIIOn‐ScreenUserInterface(OSUI)afteryou

installtheParagonsystem,soherearesomebasicsofOSUItofamiliarize

yourselfbeforestartingyourinstallation.Oncetheuserstationandthe

attachedequipmentareinplaceandpoweredon,activatetheOSUIby

QUICKLYpressingthede

faulthotkey(ScrollLock)twiceonanattached

keyboard.EachOSUImenucontainsthefollowingsections:amenu‐title

line,amenu/screenbody(fortextandfields),aprompt/messagebar,and

astatuslinethatconsistsof:

• ThecurrentOSUIhotkey

• Scan/Skipfunctionstatus

• NCS(NumLo

ck,CapsLock,andScrollLock)statusindicator

• Acommunication‐speedindicator(“L”forlowor“H”forhigh,

whichwilldependonyourParagoncomponents)showingthe

communicationspeedbetweentheuserstationandBaseStation.



1

Menuname

2

OSUImainscreen(showingmenuoptionsandfields)

3

Messagebar
