Digital Monitoring Products XR500 Series Canadian Programming Guide

60

SToP

Stop

20.1

STOP

Stop

Save Programming

WHEN ANY PANEL PROGRAMMING IS CHANGED, THE STOP ROUTINE MUST BE RUN

AND ‘SAVING PROGRAM’ MUST DISPLAY ON THE KEYPAD IN ORDER TO SAVE THE

PROGRAMMING CHANGES.

AttheSTOPprompt,pressinganySelectkeyallowsyoutoexittheProgrammer

functionofthepanel.Whenselected,thepanelperformsaninternalresetand

exits the programmer.

TheSTOProutinecausesthefollowingconditionstooccur:

• All1100SeriesDMPWirelesstransmittersareresettoNORMAL

• ThepanelStatusListiscleared

During the reset, all keypad displays are momentarily blank for two seconds. After

the reset, the programming function terminates and the keypads return to the status

list display.

TheSTOPpromptdoesnotdisarmthesystem.Anynewareasorzonesthatwere

added during programming are not armed until the system is disarmed and armed

again.

Missing LX-Bus™ Modules Displayed

TheProgrammerincludesafeaturefollowingtheSTOProutinethatdisplaysthe

nameofanyprogrammedLX-Busmodulenotcurrentlyconnectedtothepanel.For

example,ifyouhadenabledanyLX-Busoptionsandnotyetinstalleda481LX-Bus

ExpansionCard,aftertheSTOProutinethepaneldisplaysNOLXBUSCARD.Thisisa

helpful reminder to install the card. This feature can also be a troubleshooting tool

to indicate a problem if you installed the card and this message still displays. The

followinglistshowsthedifferentmessagesandtheirassociatedLX-Buscards.

Keypad Display Missing Card

NO LXBUS CARD 481LX-Bus™ExpansionCard

NO PRINTER CARD 462PPrinterInterfaceCard

NO HOST CARD 462NNetworkInterfaceCard

  (withNETWORKcommunicationselected)

The above messages clear automatically from the keypad after a few moments.

Power Up

WhentheXR500SeriesCanadianpanelispoweredupafteranACpowerfailure,

any zone transitions are not recognized for 120 seconds. Normal zone processing

resumes at the end of the 120 seconds.

Set Lockout Code

21.1

SET LOCKOUT CODE

Set Lockout Code

PressingCOMMANDattheSTOPpromptdisplaysSETLOCKOUTCODE.Thisallows

you to program a code that is then required to gain access to the panel internal

Programmer through the keypad. You can change this code at any time to any

combinationofnumbersfromthreetovedigitslong.Youdonotneedtoenter

leading zeros when using the lockout code. Initializing the panel does not clear a

LockoutCode.LockoutCodescanbechangedthroughRemoteLink.

Onceyouhavechangedthecode,itisimportanttowriteitdownsomewhereand

storeitinasafeplace.LostLockoutCodesrequirethepaneltobesentbackto

DMPforrepair.YoumaycancelaLockoutCodebyentering00000attheSetLockout

Code command.

Lockout Code restriction

DonotsetaLockoutCodehigherthan65535.

SeT loCkouT Code
