Digital Monitoring Products XR500 Series Canadian Programming Guide
32
bell oPTionS
Bell Options
10.1
BELL OPTIONS
Bell Options
This section allows you to program the panel bell output functions.
10.2
BELL CUTOFF: 15
Bell Cutoff Time
Enterthemaximumtimefrom1to99minutestheBellOutputremainson.Ifthe
areaisdisarmed,thecutofftimeresets.Enter0(zero)toprovidecontinuousbell
output. The default is 15 minutes.
Note: To support the Alarm Verify feature on an All/PerimeterorHome/Sleep/Away
system, set the Bell Cutoff Time to greater than 0.
Note: For SIA CP-01 False Alarm Reduction Installations, the Bell Cutoff Time must
be set to a minimum of six (6) minutes.
10.3
BELL TST NO YES
Automatic Bell Test
SelectYEStoturnontheBellOutputfor2secondseachtimethesystem is
com pletely armed from a keypad.ThistestisdelayeduntiltheClosingWait
acknowledgeisreceived(ifprogrammed).IftheClosingWaitacknowledgeisnot
receivedwithin90seconds,thebelltestdoesnotoccur.Armingperformedfroman
ArmingzoneorfromRemoteLink™doesnotactivatetheBellTest.
10.4
BELL OUTPUT: 0
Bell Output
EntertheoutputnumberwhenneededtofollowthepanelBellOutputoperationfor
allactionandoffconditions.Enter0(zero)todisable.
Note:WhenBELLACTIONissettoTforTemporalCode3,theBellOutputactionfor
anLX-Busoutputispulse.
10.5
BELL ACTION . . . . .
Bell Action
ThissectiondenesthetypeofBellOutputforzonealarms.PressCOMMANDto
displaythedefaultBellOutputforeachzonetype.PressanySelectkeyandenter
SforaSteadyBellOutput,PforaPulsedoutput,TforaTemporalCode3output,
andNfornoBellOutput.
Note:TroubleconditionsdonotactivatetheBellOutput.
10.5.1
FIRE TYPE: P
Fire Bell Action
DenesBellActionforFireTypezones.ThedefaultisP.
10.5.2
BURGLARY TYPE: S
Burglary Bell Action
DenesBellActionforBurglaryTypezonesandExitErroroutput.ThedefaultisS.
10.5.3
SUPRVSRY TYPE: N
Supervisory Bell Action
DenesBellActionforSupervisoryTypezones.ThedefaultisN.
10.5.4
PANIC TYPE: N
Panic Bell Action
DenesBellActionforPanicTypezones.ThedefaultisN.
10.5.5
EMERGNCY TYPE: N
Emergency Bell Action
DenesBellActionforEmergencyTypezones.ThedefaultisN.
10.5.6
AUXLRY 1 TYPE: N
Auxiliary 1 Bell Action
DenesBellActionforAuxiliary1Typezones.ThedefaultisN.
10.5.7
AUXLRY 2 TYPE: N
Auxiliary 2 Bell Action
DenesBellActionforAuxiliary2Typezones.ThedefaultisN.
