Digital Monitoring Products XR500 Series Canadian Programming Guide
42
PC log rePorTS
PC Log Reports
17.1
PC LOG REPORTS
PC Log Reports
ThissectionallowsyoutoprogramthetypesofPCLogReportsthepanelsends
throughthe462NNetworkInterfaceCardorthroughtheJ21SerialConnector
directly on the XR500 Series Canadian panel. The reports include information such
as the type of activity, time and date of the activity, and user name and number.
These data reports can be accessed from a PC using the Advanced Reporting Module.
SeetheInstallationGuide(LT-0681CAN)fordetailedJ21setupinformationorthe
User’sGuide(LT-0683CAN)formoreinformation.
Note:ThenetworkconnectionthatsendsPCLogReportsisnotmonitoredfor
networktrouble.ThePCLogReportsoptionshouldNOTreplacetheprimary
communication method or act as a backup communication method.
If there is trouble with the network connection, the panel continues to attempt to
sendthePCLogReportsuntiltheconnectionisreestablished.Thepanelthensends
the reports. A Network Trouble message is NOT sent if the connection is lost since
thisreporttoolisnotdesignedtobemonitoredbyareceiver.ThePCLogReports
have the lowest priority of panel reports sent.
Forinformationaboutthe462NcardcapabilitieswithPCLogReportsandNetwork
Communicationmethod,see462NCardExamplesintheAppendix.
Note:ThePCLogAddressStringenteredCANNOTbethesameasthatenteredin
Communication.
17.2
COMM TYPE: NONE
Communication Type
NONE NET 232
SelecttheCommunicationTypetosendthePCLogReports.DefaultisNONE.
17.3
NET IP ADDRESS
Net IP Address
ThisoptiondisplayswhentheCommunicationTypeforPCLogReportsisNET.Enter
theIPaddresscontainingupto16characters.TheNetIPAddressmustbeuniqueand
cannot be duplicated on the network. Enter all 12 digits and leave out the periods.
Forexample,enterIPaddress192.168.0.250as192168000250.Theperiodsdisplay
automatically.
17.4
NET PORT 2001
Net Port
ThisoptiondisplayswhenCommunicationTypeforPCLogReportsisNet.Enterthe
Portnumber.Validnumbersarefrom0to65535.Defaultis2001.
17.5
232 COMM PORT: O
232 Communication Port
ThisoptiondisplayswhenCommunicationTypeforPCLogReportsis232.Toenable
PCLogReports,selecteithertheon-boardconnector(O)orselectA,B,C,DorEfor
thecorrespondingslotinuseontheDMPModel462NNetworkInterfacecard.The
slotsarelabeledfromlefttoright,beginningwithA.DefaultisO.
SettheXR500SeriespanelJ23jumpertoRandbrieyresetthepanelusingtheJ16
jumpertoactivateRS-232operation.
17.6
232 SETUP:
232 Setup
ThisoptiondisplayswhenCommunicationTypeforPCLogReportsis232.Enterup
to 32 characters.
17.7
ARM/DIS NO YES
Arm and Disarm Reports
Sendsarming,disarmingandLatetoCloseevents.Includestheareanumber,name
and action, the user number and name, and the time and date.
17.8
ZONE NO YES
Zone Reports
Sends changes in the status of active zones. Includes the zone number, name, type,
theaction(alarm,trouble,bypass,etc.),usernumber(ifapplicable),andarea
name.ForaWalkTest,VerifyandFailmessagesaresentforeachzone.
17.9
USR CMDS NO YES
User Command Reports
Sends user code changes, schedule changes, and door access denied events.
