XR500 Series Canadian Programming Guide Digital Monitoring Products

21

deviCe SeTuP

6.15.9

REQUIRE SITE

CODE? NO YES

Require Site Code

Press the top row Select key under YES to use a site code.

InadditiontoUserCodeverication,dooraccessisonlygrantedwhenanyonesite

codeprogrammedattheSITECODEENTRYoptionmatchesthesitecodereceivedin

theWiegandstring.

6.15.9 .1

SITE CODE 1: -

Site Code Display

 Youcanprogramuptoeightthree-digitsitecodes.Sitecoderangeis0-999.

Any previously programmed site codes display. Dashes represent blank site

codes.

 SiteCode1displaysrst.Enterathree-digitsitecodenumberfollowedby

the command key to advance to the next prompt, Site Code 2. To delete

an existing site code, press any select key. Either enter a new site code

followed by command, or press command to leave blank and continue to the

 nextsitecode.Repeatthesestepstochange,delete,oraddupto8site

codes.

Note: A card with a site code greater than three digits cannot be used.

Use only cards with three-digit site codes.

6.15.10

NO OF USER CODE

DIGITS: 5

Number of User Code Digits

The734modulerecognizesusercodesfromfourtotendigitsinlength.Pressany

toprowSelectkeytoenterausercodedigitlengthbetween4-10digits.This

number must match the user code number length being used by the panel. Default

is5.ForanXR500AreaSystem,use4to10digits(typically5).Forallothersystems

and panels, use 4 digits.

Anyselectionabove5digitsrequireentryofthecustomcarddenitionswithcustom

siteandusercodepositionsfortheWiegandstring.Whensearchingthebitstring

fortheusercode,thedigitsareidentiedandreadfromlefttoright.

6.15.11 Degraded Mode

Thisoptiondenestherelayactionwhencommunicationwiththepanelhasnot

occurredforveseconds.PressanytoprowSelectkeytodisplayrelayaction

options.PresstheBackArrowkeytoreturntotheNOOFUSERCODEDIGITS:.

Choose the Degraded Mode Action required.

 PresstherstSelectkeytochooseOFF[Default] (RelayAlwaysOff) — The relay

doesnotturnonwhenanyWiegandstringisreceived.OffdoesnotaffectanyREX

operation.

 PressthesecondSelectkeytochooseSITE(AcceptSiteCode) — Door access

isgrantedwhentheWiegandsitecodestringreceivedmatchesanysitecode

programmedatSITECODEENTRY.FordetailsreferbacktotheREQUIRESITECODE

option.

 PressthethirdSelectkeytochooseANY(AnyWiegandRead) — Door access is

granted when any Wiegandstringisreceived.

Press the fourth Select key to chooseON(RelayAlwaysOn)—Therelayisalwayson.

 PresstheCOMMAND key to display the next action.

 PresstherstSelectkeytochooseLAST(KeepLastState) — The relay remains in the

same state and does not change when communication is lost.

Afterchoosingtheaction,theDEGRADEDMODEoptionandthenewlydenedaction

display.

Programmingisnowcomplete.PresstheCOMMANDkeytodisplayDEVICENO.Press

the Back Arrow toreturntotheNOOFUSERCODEDIGITSoption.

DEGRADED MODE:

RELAY ALWAYS OFF

DEGRADED MODE:

ACCEPT SITE CODE

DEGRADED MODE:

ANY WIEGAND READ

DEGRADED MODE:

RELAY ALWAYS ON

DEGRADED MODE:

OFF SITE ANY ON

DEGRADED MODE:

PRESERVE LAST

DEGRADED MODE:

LAST
