Digital Monitoring Products XR500 Series Canadian Programming Guide
58
zone informaTion
19.18
SWGR BYP NO YES
Swinger Bypass
Selecting YES allows the zone to be swinger bypassed by the panel according to the
specications programmed inSwinger BypassTrips and ResetSwinger Bypass. The
Bypass condition displaysin thekeypad Status List. SelectingNO disables swinger
bypassing for this zone.
How it works
Ifwithinonehour,azonetripsthetotalnumberoftimesasspeciedinSwinger
Bypass Trips, the panel bypasses it until the following conditions occur; the area
in which the zone is assigned is disarmed, the zone is manually reset through the
BypassZones?keypadUserMenufunction,thezoneremainsnormalforonehourand
the Reset Swinger Bypass is YES.
Ifthezonetripsfewerthanthespeciedtimeswithinonehour,thebypasstrip
counterreturnsto0(zero)andtheprocessmustberepeated.
A report of the swinger bypass is sent to the receiver if Bypass Reports is YES.
19.19
PREWARN KEYPADS:
Prewarn Keypad Addresses
Attheentrydelaystart,allkeypadaddressesselectedheredisplayENTERCODE:-.
Ifyouwanttheprewarntosoundatall16addresses,leavethedefaultsetting.
To delete an address, press the matching number on the keypad. To disable
prewarning at all keypads, press a top row Select key to clear the addresses shown.
PresstheCOMMANDkeywhentheaddressselectioniscomplete.
Theprewarntonestopsatthekeypadwheretherstusercodedigitisentered.If
nokeysarepressedforvesecondsoraninvalidusercodeisentered,theprewarn
tone resumes at that keypad.
19.20
ENTRY DELAY: 1
Entry Delay
Select the entry timer for this zone. Entry timers 1 to 4 are programmed in System
Options.
19.21
RETARD NO YES
Zone Retard Delay
WhenyouselectYES,thezoneoperateswiththezoneretarddelay.Theretard
func tions only in zone short condi tions.
The zone must re main shorted for the full length of the re tard de lay before the
panelrecognizesitscondition.IfyouselectNO,thezoneoperateswithoutaretard
delay.
19.22
PRESGNL KEYPADS:
Presignal Keypad Addresses
You can enable any combina tion of keypad addresses to sound a presignal tone
during the time a zone is in retard delay. The presignal tone si lences when the zone
restores or the re tard delay expires.
To en able a presignal ad dress, press any top row Select key followed by the number
ofthekeypadaddress.Youcanenablethepresignalforall16keypadaddresses.
To disable a presignal address press the matching number digit again. Press the
COMMANDkeywhentheaddressselectioniscomplete.ThePresignalpromptisonly
displayed when Retard is selected as YES.
19.23
FAST RSP NO YES
Fast Response
SelectYEStoprovideazoneresponsetimeof167ms.SelectNOtoprovideanormal
zoneresponsetimeof500ms.Zones500to999haveaxedresponsetimeanddo
not display this prompt.
19.24
CRS ZONE NO YES
Cross Zone
Select YES to enable cross zoning for this zone. Cross zoning requires one or more armed
zones to fault within a programmed time before an alarm report is sent to the receiver.
Whentherstcrosszonedzonetrips,thecrosszonetimespeciedinSystem
Optionsbeginstocountdown.Whenasecondcrosszonedzonetripsortherst
zone trips a second time before the end of the count down, the bell action assigned
to the zone activates and the panel sends an alarm report for both zones.
If no other cross zoned zone trips before the cross zone time expires, the panel
sends only a zone fault report to the receiver.
Cross zoning is not compatible with all zone types: You can not enable cross zoning
for Fire verify zones or for any Fire zones that have Retard Delay enabled.
