XR500 Series Canadian Programming Guide Digital Monitoring Products
51
zone informaTion
19.9
NEXT ZN? NO YES
Next Zone
SelectYEStoterminatezoneprogramming.ThedisplayreturnstoZoneNumber,
allowingyoutoenteranewzonenumber.SelectNOtomakealterationstothe
AlarmActionforazone.AlarmActionisdenedbeginningwithsection16.12.
Toprogramzonesforwirelessoperation,selectNOattheNEXTZONE-NOYES
option.TheWIRELESSNOYESoptiondisplays.Ifthezoneyouareprogramming
isintendedforwirelessdevices,selectYES.SelectNOtocontinueprogramming
non-wirelesszonesinthe500to999range.
• Zones400to449canbeprogrammedfor1100SeriesKeyFobs.
• Zones500to699canbeprogrammedforFASeriesWireless.
• Zones500through999canbeprogrammedforDMP1100SeriesWireless.
DMP Wireless
For a DMP 1100X Wireless Receiver set the House Code from 1 to 50. See House Code programming
inSystemOptions.Zones500through999canbeprogrammedasWirelesszones.SettheXR500Series
CanadianpanelJ23jumpertoXtoenableon-boardDMPWirelessoperation.Brieyresetthepanelusing
theJ16jumpertoactivateWirelessoperation.RefertotheXR500SeriesCanadianInstallationGuide
(LT-0681).
For an 1100 Series Key Fob see section 19.11.
For an FA Series Remote Wireless Receiver see section 19.12.
NOTE: AllwirelessprogrammingisstoredintheXR500SeriesCanadianpanel.The1100XWireless
Receiver obtains the necessary programming information from the panel each time the receiver powers
up,whentheprogrammerSTOProutineisselectedorthepanelisreset.Thereceivermemoryrefresh
takes up to 10 seconds to complete depending on the number of wireless zones programmed and the Red
LEDremainsonduringthistime.Normalreceiveroperationisinhibitedduringthememoryrefreshperiod.
19.10 Wireless
Select YES to program this zone as a DMP wireless zone. You must program
the wireless House Code prior to adding DMP wireless zones to the system. See
HouseCodeprogramminginSystemOptions.DefaultisNO.
19.10.1
TRANSMITTER
SERIAL#: XXXXXXXX
Serial Number Entry
Entertheeight-digitserialnumberfoundonthewirelessdevice.
ALREADY IN USE
ZONE NUMBER: XXX
This message displays when the serial number is already programmed for
another zone. The programmed zone number displays.
19.10.2
TRANSMITTER
CONTACT:XXXXXXXX
Contact
This option displays if the serial number entered is for an 1101 or 1103 Universal
Transmitteror1114WirelessFour-ZoneExpander.Pressanytoprowkeyto
select the contact.
TRANSMTR CONTACT
INT EXT
This option displays when programming an 1101 or 1103 Transmitter. Select INT
to use the internal reed switch contacts. Select EXT to connect an external
devicetothe1101or1103terminalblock.DefaultisINTERNAL.
ByallowingbothoftheModel1101or1103transmittercontacts(INTand
EXT)tobeusedatthesametime,twozonesmaybeprogrammedfrom
onetransmitter.Whenusingbothcontacts,youmustuseconsecutivezone
numbers.Zones531and532orzones890and891areacceptablezone
assignments.
Forexample,programtransmitterserialnumber01345678asZone521with
anINTcontacttypeandZone522withanEXTcontacttype.Thesameserial
number is used for both zones.
ZONE INFORMATION
WIRELESS? NO YES
