XR500 Series Canadian Programming Guide Digital Monitoring Products
53
zone informaTion
1100 Series Key Fobs
For an 1100 Series Key Fob set the House Code from 1 to 50. See House Code programming in System
Options.Onlyzones400to449canbeprogrammedas1100SeriesKeyFobzones.Refertothe1100
SeriesKeyFobProgrammingSheet(LT-0706)suppliedwiththe1100XWirelessReceiverandthe1100Series
KeyFobInstallGuide(LT-0703)asneeded.
To operate arming and disarming properly, the Key Fob should be assigned to a User Number with
appropriate area assignments, however, the User Number does not have to exist at the time the Key
Fob is programmed. The Key Fob User Number can be added later by the User.
ThefollowingprogrammingcontinuesfromtheZoneNumbersectionwhenzone400-449isselected.
19.11.1
KEY FOB USER
NUMBER: XXXX
Key Fob User Number
EntertheUserNumber(1-9999)usedtoidentifythekeyfobuserandtheir
arming and disarming authority. Default is blank.
USER XXXX
NOT IN USE
Displays when the User Number entered does not exist in User Code
programming. The key fob can be added, but the user must eventually be
added to cause the key fob to operate.
19.11.2
TRANSMITTER
SERIAL#: XXXXXXXX
Key Fob Serial Number
Entertheeight-digitserialnumberfoundonthewirelessdevice.
19.11.3
TRANSMITTER
SUPRVSN TIME: 0
Key Fob Supervision Time
Press any top row key to select the supervision time required for the key fob
zone.PressCOMMANDtoacceptthedefaulttime.Defaultis0forkeyfobs.
SELECT MINUTES:
0 3 60 240
Press the Select key under the required number of minutes. The key fob must
check in at least once during this time or a missing condition is indicated for
that zone. 1100 Series key fobs automatically checkin based on the supervision
time selected for the wireless zone, no additional programming is needed.
Zero(0)indicatesanunsupervisedtransmitter.
Note:Whenthepanelisresetorareceiverisinstalledorpowereddownand
powered up, the supervision timer restarts for all wireless zones.
19.11.4
NO. OF KEY FOB
BUTTONS: X
Number of Key Fob Buttons
Enterthenumberofbuttons(1,2,or4)onthekeyfobbeingprogrammed.
Note:Ifthekeyfobisaone-buttonmodel,programmingcontinuesatthe
ButtonActionsection.Defaultbuttonassignmentforone-buttonkeyfobsisa
PanicAlarm(PN)withnooutputassigned.
19.11.5
BUTTON:
TOP BTM LFT RGT
Key Fob Button Selection (Four Buttons)
Thispromptonlydisplaysifthekeyfobbeingprogrammedisafour-button
model. Press the Select key under the key fob button to program. The
followinglistidentiesthedefaultbuttonassignments:
TOP Armingwithnoareasassigned
BTM Disarming with no areas assigned
LFT PanicAlarm(PN)withnooutputassigned
RGT ArmingwithArea1assigned
19.11.6
BUTTON:
TOP BTM
Key Fob Button Selection (Two Buttons)
Thispromptonlydisplaysifthekeyfobbeingprogrammedisatwo-button
model. Press the Select key under the key fob button to program. The
followinglistidentiesthedefaultbuttonassignments:
TOP Armingwithnoareasassigned
BTM Disarming with no areas assigned
