XR500 Series Canadian Programming Guide Digital Monitoring Products

11

CommuniCaTion

3.22

RETRY SECONDS: 6

Retry Seconds

This option displays for NET or 232 Communication Types.

Enterthenumberofseconds(between6and15)thepanelshouldwaitbefore

retrying to send a message to the receiver if an acknowledgment was not received.

The panel retries as many times as possible for a period of one minute before

sending a network trouble message. For example, if retry time is set to 15, the

panelretriesfourtimes.ThedefaultRetryTimeis6seconds.

Note:IfTCPisenabled,theminimumRetryTimeprogrammedis6seconds.

3.23

SUB CODE NO

Substitution Code

ThisoptiondisplayswhentheCommunicationTypeisNET,CELLor232.ThePanel

Substitution Code increases the level of security by helping to ensure that the panel

sending the message to the receiver has not been substituted by another panel. The

defaultisNO.

Select YES to send a substitution code with every message.

SelectSHARED(SHR)tousethesamesubstitutioncodeasoperatingintheprevious

path.

3.24

232 COMM PORT: O

232 Communication Port

This option displays when Communication Type is 232.

ThisoptionsetsthephysicalRS-232porttotheon-boardconnectororoneoftheDMP

Model461InterfaceAdaptorCardslotslabeledA,B,C,D,orE.UseslotAifusinga

462NNetworkInterfaceCardwithorwithoutthe461card.

EnterOtousetheon-boardconnector.SettheXR500SeriesCanadianpanelJ23

jumpertoRandbrieyresetthepanelusingtheJ16jumpertoactivateRS-232

operation.DefaultisO(On-board).

3.25

-

-

232 SETUP:

232 Setup String

This option displays when the Communication Type is 232. Enteruptotwolinesof16

characters to equal up to 32 characters for the destination address that may include

an IP address.Example:IfusingaDMPiCOM,enterAT#UCXXX.XXX.XXX.XXX#PPPPP

where X is the IP address and P is the port number.

3.26

893A: NO YES

893A

This option displays when the Communication Type is DD or CID.

The893AoptionallowsreportstobesenttothereceiveronasecondDDlineusing

the893Amodule.DefaultisNo.

Whenusingthisoption,TestReportmessages(S07AutomaticRecallTestor

S88UnrestoredSystemRecallTest)aresenttothereceiveratthefrequency

programmedinTestFrequency,alternatingbetweentherstandsecondphoneline.

Forexample,aDDpathwithan893Amodulesetfordailytestreportfrequency

sends a test report through phone line 1 one day and phone line 2 the next day.

If893AoptionissettoYES,enteruptoa3digitprextobedialedbeforethe

secondphonenumber.Ifnoprexisentered,thesecondphonenumberisdialedas

originally entered.

3.27

ALARM SWITCH: 1

Alarm Switch

This prompt displays for DD or CID Communication Types.

Enter the number of attempts to send an alarm message before switching to the next

path.Rangeisfrom1to10.Allnon-alarmmessagesaresentfor10attemptsonthe

dialer before a switch is initiated. If the path immediately following this channel is

not a backup path, this option has no effect. Default is 1.

3.28

DUPLICATE ALARMS

Duplicate Alarms

ThispromptdisplaysforBACKUPpaths.IfYesisselected,thecurrentbackuppath

duplicates all alarms occurring on its group primary path. Default is No.

D E

O A B C

NO YES SHARED

NO YES

-

2ND LINE PREFIX:
