Digital Monitoring Products XR500 Series Canadian Programming Guide

10

CommuniCaTion

3.15

RECEIVER PORT -

Receiver Port

2001

Enterthereceiverportnumber.Validrangeis1to65,535.Defaultis2001.

3.16

FIRST PHONE NO.

First Telephone Number

This option displays only if the Communication Type is DD or CID.

Thisistherstnumberthepaneldialswhensendingreportstothereceiver.Phone

numberscanhavetwolinesof16characterseachtoequalupto32characters.

EnterPtoprogramathree-secondpauseinthedialingsequence.ThePcharacter

counts as part of the 32 allowable characters.

EnterRastherstcharacterforrotary(pulse)phonefunction.TheRcharacter

counts as part of the 32 allowable characters.

Call Waiting: You can place the “*70P”(Star,Seven,Zero,Pause)inthetelephone

numberrstpositiontocancelCallWaiting.For example, program NET with second

lineDDandphonenumber*70P555-1212,andyouhaveNETwithCallWaiting

cancelled on the second line.

Caution:Acallwaitingcancelprogrammedonanon-callwaitingtelephoneline

would prevent communication to the central station.

3.17

SECOND PHONE NO.

Second Telephone Number

Thepaneldialsthesecondnumberwhentwosuccessivetriesusingtherstnumber

fail. If the panel cannot reach the receiver after two attempts using the second

number,itreturnstotherstnumberandmakestwoadditionalattempts.Atotalof

tendialingattemptsaremadeusingtherstandsecondphonenumbers.

Each number can be up to 32 characters in length in cluding any P or R char acters

entered for pause or rotary connections or call waiting cancel option.

Should all ten attempts fail, the panel continues to attempt sending the message

using the next programmed path. If all programmed communication paths fail, the

panel clears the communication buffer and makes one communication attempt each

hourtosendaTRANSMITFAILED(S87)reporttothereceiver.AccesstheUserMenu

Display Events feature to view the report information not sent to the receiver or

downloadthereportwithDMPRemoteLink™software.

3.18

ADVANCED? NO YES

Advanced Programming

Select Yes to enter the Advanced Programming menu for the communication path

currently being programmed.

3.19 First GPRS APN

EntertherstAPN(AccessPointName).Thisallowsanaccesspointforcellular

communication and is used to connect to a DNS network. The APN may contain two

linesof16characterstoequal32characters.DefaultissettoSECURECOM400.

Second GPRS APN

EnterthesecondAPN(AccessPointName).Thisworksasabackupincasetherst

APNfails.TheAPNmaycontaintwolinesof16characterstoequal32character

DefaultissettoSECURECOM400.

3.20

FAIL TEST HRS: 0

Fail Test Hours

This option sets the frequency for a Backup or Adaptive path to send a test report

when the closest previous path fails within its path group.

For example, if a backup path is programmed to send a weekly test report and the

Fail Test Frequency is set to 2 hours, when the previous path fails within its group,

the backup path starts sending a test every 2 hours until the previous path restores.

If Fail Test Frequency is set to 0, test reports are sent only according to Test Report

programming. Range is 0 to 24 hours. Default is 0.

3.21

PROTOCOL: TCP

Protocol

This option displays only when Communication Type is NET.

Select TCP to communicate over the network using TCP protocol. Select UDP to

communicate using UDP protocol. Default is TCP.

SECURECOM400

-

FIRST GPRS APN

SECURECOM400

-

SECOND GPRS APN
