Digital Monitoring Products XR500 Series Canadian Programming Guide
36
ouTPuT informaTion
Output Information
12.1
OUTPUT INFO
Output Information
This section allows you to program wireless outputs and name wired outputs.
12.2
OUTPUT NO. X X X
Output Number
Enteranoutputnumber.Entryrangeis1to6,450to474,480to499,500to999.
12.3
OUTPUT NAME
Output Name
Thissectionallowsyoutodenea32characteralphanumericnameforanyoutput
numbers. The name can display on the keypad when a user performs the browser
featureatOutputsOn/Off.SeetheXR100/XR500User’sGuide(LT-0683CAN)
Appendix for browser operation.
12.4 Output Real-Time Status
SelectingYESallowsReal-TimeStatusreports,suchasOutputON,OFF,PULSE,or
TEMPORALtobesentusingPCLogreports.SelectingNOdisablesReal-TimeStatus
forthisoutputdevice.DefaultisNO.
12.5
SERIAL#: XXXXXXXX
Serial Number
This option and the next option only display when the output number entered is for
awirelessoutput.Entertheeight-digitserialnumberfoundonthewirelessdevice.
ALREADY IN USE
OUTPUT NO: XXX
This message displays when the serial number is already programmed for another
output. The programmed output number displays.
12.6
SUPRVSN TIME: 240
Supervision Time
Press any top row key to select the supervision time required for the wireless
output.PressCOMMANDtoacceptthedefaulttime.Defaultis240minutes.
Note:RefertotheWirelessCheck-inandSupervisionTimeDenitionssectionofthe
Appendix for supervision information.
SELECT MINUTES:
0 3 60 240
Press the Select key under the required number of minutes. The wireless output
must check in at least once during this time or a missing condition is indicated for
thatoutput.Zero(0)indicatesanunsupervisedtransmitter.
Note:Whenthepanelisreset,areceiverisinstalledorpowereddownandpowered
up, or programming is complete, the supervision timer restarts for all wireless
outputs.
OUTPUT REAL-TIME
STATUS
NO YES
