XR500 Series Canadian Programming Guide Digital Monitoring Products
55
zone informaTion
ARM AREAS: PERIM
InanAll/PerimeterorHome/Sleep/Awaysystem,thisspeciestheareatobe
armedbytheKeyFobbuttonbeingprogrammed.ForAll/Perimetersystems,
choosePERIMorALL,forHome/Sleep/AwayorHome/Awaysystems,choose
HOME,SLEEP,orAWAY.
Note:Areas3andhigherinanAll/Perimetersystem,andareas4andhigherina
Home/Sleep/Awaysystemarenotavailableforuse.
Afterselectingtheareas,forone-buttonkeyfobstheZoneNo.:prompt
displays.Fortwo-buttonorfour-buttonkeyfobs,theKeyFobButtonSelection
option displays to program additional buttons.
19.11.10
OUTPUT NO: XXX
Output Number
YoucanspecifyarelayoutputtooperatewhenOUT(Output),PN(Panic),PN2
(Panic2),EM(Emergency),orEM2(Emergency2)isselectedforakeyfob
ButtonActionandthebuttonispressed.Validrangeis1to6,500to999,
D1toD16,orG1toG20.ForanoutputturnedonbyaPN,PN2,EM,orEM2
button action, the output turns off when any area is disarmed.
To enter an output number, press a top row Select key followed by the output
number.PresstheCOMMANDkey.
19.11.11
OUTPUT ACTION:
yyy: XXXXXXXX
Output Action
Thisoptionallowsyoutodenetheoutputaction(STD,PLS,MOM,TGL,OFF)
for the selected output number. The default is Steady.
yyy=thenameofthebuttonbeingprogrammed(TOP,BTM,LFT,RGT).
xxxxxxxx=thecurrentlydenedoutputaction.
OUTPUT ACTION?
STD PLS MOM TGL
STD (Steady) - The output is turned on and remains on.
PLS (Pulse) - The output alternates one second on and one second off.
ThepulsingrateforaModel716relayattachedtotheLX-Busis1.6seconds.
Note:PulseisnotavailableforkeyfobbuttonoutputprogrammedD1toD16or
G1toG20.
MOM (Momentary) - The output is turned on only once for one second.
TGL (Toggle) - The output alternates between the on state and off state. Each
button press toggles the output state.
Note:ToggleisnotavailableforkeyfobbuttonoutputprogrammedG1toG20.
OUTPUT ACTION?
OFF
OFF (Off) - The output is turned off. If programmed, the output was turned
on by some other means such as another button press, a zone action, or a
schedule.
Note:WhentheoutputisassignedtoPN/PN2orEM/EM2buttonactionandis
turned on, the output turns off when any area is disarmed.
Whentheoutputactionissteady,pulseortoggleandtheoutputisturnedon,
the output remains on until:
— the output cutoff time expires
— the output is reset from the keypad menu
— toggled off
19.11.12
NEXT ZONE NO YES
Next Zone
SelectYEStoreturntotheZONENO:-prompttoprogramanewzone.Select
NOtodisplaytheAlarmActionoption.
Note: AllwirelessprogrammingisstoredintheXR500SeriesCanadianpanel.The1100XWireless
Receiver obtains the necessary programming information from the panel each time the receiver powers
up,whentheprogrammerSTOProutineisselectedorthepanelisreset.Thereceivermemoryrefresh
takes up to 10 seconds to complete depending on the number of wireless zones programmed and the Red
LEDremainsonduringthistime.Normalreceiveroperationisinhibitedduringthememoryrefreshperiod.
