Digital Monitoring Products XR500 Series Canadian Programming Guide
28
SySTem oPTionS
9.6
CRS ZONE TM: 4
Cross Zone Time
Enterthetimeallowedbetweenzonefaults.Whenzonesarecrosszoned,thesame
zone or a second cross zoned zone must fault within this time in order for an alarm
report for both zones to be sent to the receiver. If the cross zone time expires
withoutthesecondzonefaulting,onlyazonefaultfromtherstzoneisreported.
Cross-zonetimecanbefrom4to250seconds.Entering0(zero)disablesthis
function. Default is 4. See the Appendix.
9.7
RETARD DELAY: 10
Zone Retard Delay
Enter the retard time assigned to Fire, Supervisory, Auxiliary 1, Auxiliary 2, Arming,
and Panic type zones. The retard delay only functions when the zone is shorted.
The zone must remain shorted for the entire length of the Retard Delay before being
recognizedbythepanel.TheZoneRetardDelaycanbefrom1to250seconds.
Enteringa0(zero)disablesthisfunction.
9.8
PWR FAIL HRS: 1
Power Fail Delay
ThisoptiontracksthedurationofanACpowerfailure.WhentheACpowerisofffor
the length of the programmed delay time, an AC power failure report is sent to the
receiver.Thedelaytimecanbefrom1to15hours.Enteringa0(zero)sendsthe
powerfailurereportaftera15-seconddelay.Thedefaultsettingis1.
9.9
SWGRBYPS TRIPS: 1
Swinger Bypass Trips
Enterthenumberoftimes(1or2)azonecangointoanalarmortroublecondition
within one hour be fore being auto matically bypassed. You can select one or two
trips. Bypassed zones are auto matically reset when the area they are assigned to is
disarmed.All24-hourzonesareresetwhenanyareaofthesystemisdisarmed.A
programmingStopoperationrestoresabypassedzone.Entering0(zero)disables
this function. Default is 1.
How it works
Thepanelhourtimerstartsat59minutespastthehour.Ifthehourtimerexpires
beforethetripcounterisexceeded,thetripcounterreturnsto0(zero).Ifthetrip
counter is exceeded before the hour expires, the zone is auto matically bypassed by
the panel. A Bypass Re port is sent to the receiver if Bypass Re ports is YES.
9.10
RST SBYP NO YES
Reset Swinger Bypass
WhenYESisselected,anautomaticallybypassedzoneisresetifitremainsina
normal condition for one complete hour after being bypassed. A report of the
automatic reset is sent to the receiver if Bypass Reports has been se lected as YES.
DefaultisNO.
9.11
TIME CHG NO YES
Time Zone Changes
This function allows the panel to request automatic time changes from the DMP
SCS-1RReceiveronPath1.Forthereceivertosendtimechanges,itmustbe
programmed to send time changes and must be receiving time change updates from
the network automation computer at least every 24 hours. Default is YES.
HRS FROM GMT: 6
WhentimezoneisprogrammedYES,enterthenumber(0-23)thatindicatesthe
GreenwichTimezone(GMT)wherethepanelislocated.Thedefaultis6.
