XR500 Series Canadian Programming Guide Digital Monitoring Products
33
ouTPuT oPTionS
Output Options
11.1
OUTPUT OPTIONS
Output Options
This section allows you to program panel output options. The panel provides two
FormCrelays(1and2)andfourswitchedground(opencollector)outputsnumbered
3to6.Expandthesystemupto500additionalrelayoutputsusingJ22LX-Buson
thepanel,multiple716OutputExpanderModules,anduptoveinterfacecards.In
addition, 45 wireless outputs are available when using the 1100X wireless receiver.
RefertotheXR500SeriesCanadianInstallationGuide(LT-0681)forcomplete
information.
Select from the following output numbers:
• 1to6
• 450to474—Slowresponsetime*wirelessoutputs(activateswithin15seconds)
• 480to499—Fastresponsetime*wirelessoutputs(activateswithin1second)
• 500to999—LX-Busoutput,Relayoutput,Zoneexpansionoutput
• D1toD16—Keypaddoorstrikerelayforaddresses1-16
• G1toG20—Outputgroup
* The response time of a wireless output is the time it takes for a wireless output to
activate once the panel event occurs. You determine whether a wireless output is a
slow or fast response based on the output number assigned. A slow response output
number extends battery life, but response time may be up to 15 seconds. A fast
response output number responds within 1 second, but reduces battery life. Refer
tothespecicwirelessoutputinstallationguidetodeterminebatterylife.
11.2.1
CO OUTS: - - - - - -
Cutoff Output
Outputs1to6canbeenteredheretoturnoffafteratimespeciedinCUTOFF
TIME. To disable this option, press any Select key to clear the display then press
COMMAND.TheCutoffOutputdisplaysdasheswhennooutputsareselected.
11.2.2
CUTOFF TIME: 0
Output Cutoff Time
IfaCutoffOutput(1-6)isassigned,enteraCutoffTimeof1to99minutesforthe
outputtoremainon.Enter0(zero)forcontinuousoutput.
11.3
COMM TRBL OUT: 0
Communication Trouble Output
Enter the output number to turn on when a DD system fails to communicate on
three successive dial attempts or if the backup communication line transmits a
report.TheCommunicationTroubleOutputalsoturnsonwhenNETisselected
as the primary communication method and NET communication fails after one
minute.WhenNETcommunicationisrestoredtheCommunicationTroubleOutput
automatically turns off.
Tomanuallyturntheoutputoff,disarmanyareaorselectOfffortheoutputnumber
intheUserMenuOutputsOn/Offsection.Enter0(zero)todisablethisoutput.
11.4
FIRE ALR OUT: 0
Fire Alarm Output
Entertheoutputnumbertoturnonwhenaretypezoneisplacedinalarm.The
outputisturnedoffusingtheSensorResetoptionwhilenoadditionalretypezones
areinalarm.Enter0(zero)todisable.ThisoutputisnotcompatiblewithCutoff
Outputs.
11.5
FIRE TRB OUT: 0
Fire Trouble Output
Entertheoutputnumbertoturnonwhenaretypezoneisplacedintrouble,when
a supervisory type zone is placed in alarm or trouble, or when any system monitor
(AC,Battery,PhoneLine1orPhoneLine2)isplacedintrouble.Theoutputturnsoff
whenallreandsupervisorytypezones,orsystemmonitorsarerestoredtonormal.
Enter0(zero)todisablethisoutput.ThisoutputisnotcompatiblewithCutoff
Outputs.Thisoutputcanbeconnectedtoalamp,LED,orbuzzerusingtheDMP
Model716OutputExpansionModule.
