86 Rockwell Automation Publication 2097-UM002C-EN-P - December 2013
Chapter 5 Configure and Start Up the Kinetix 350 Drive System
Configure the Kinetix 350 Drive
Follow these steps to configure the Kinetix 350 drive.
1. Right-click the Logix5000 EtherNet/IP controller you just created and
choose New Module.
The Select Module dialog box appears.
2. Clear the Module Type Category Filter and check the Motion category.
3. Select your 2097-V3xPRx-LM drive as appropriate for your actual
hardware configuration and click Create.
IMPORTANT
To configure Kinetix 350 drive (catalog numbers 2097-V3xPRx-LM) you must be
using RSLogix
5000 software, version 20 or later, or Logix Designer Application.
