Rockwell Automation Publication 2097-UM002C-EN-P - December 2013 45
Kinetix 350 Drive Connector Data Chapter 3
Ethernet Communication Specifications
An RJ45 100 Mbit Ethernet connector (port 1) is provided on the Kinetix 350
drive. It is fully compliant to the EtherNet/IP standard. Restrict the location of
all Ethernet cabling to clean zones with minimal electromagnetic interference.
24V DC Back-up Power Specifications
The Kinetix 350 drive can use an external power supply to power the logic and
communication circuits. If an independent 24V (@ 1 A) power supply is
connected to the BP connector, the logic and communication circuits remain
active during a mains input power loss.
Attribute Value
Communication 100BASE-TX, full duplex
Auto MDI/MDIX crossover detection/correction Yes
Cabling
Rockwell Automation CAT5E shielded, 100 m
(328 ft), max
Attribute Value
Input voltage 20…26V DC
Current 500 mA
Inrush, max 30 A
