Rockwell Automation Publication 2097-UM002A-EN-P - December 2013 23
Install the Kinetix 350 Drive System Chapter 2
Transformer Specifications for Input Power
Power Dissipation Specifications
This table shows the maximum power dissipation of each drive. Use this table to
size an enclosure and calculate required ventilation for your Kinetix
350 drive
system.
Attribute Value (460V system)
Input volt-amperes 750VA
Input voltage 480V AC
Output voltage 120…240V AC
Cat. No. Power Dissipation, W
2097-V31PR0-LM 28
2097-V31PR2-LM 39
2097-V32PR0-LM 28
2097-V32PR2-LM 39
2097-V32PR4-LM 67
2097-V33PR1-LM 28
2097-V33PR3-LM 39
2097-V33PR5-LM 67
2097-V33PR6-LM 117
2097-V34PR3-LM 39
2097-V34PR5-LM 58
2097-V34PR6-LM 99
