Circuit Breaker/Fuse Specifications
While circuit breakers offer some convenience, there are limitations for their use.
Circuit breakers do not handle high current inrush as well as fuses.
Make sure the selected components are properly coordinated and meet
acceptable codes including any requirements for branch circuit protection.
Evaluation of the short-circuit available current is critical and must be kept below
the short-circuit current rating of the circuit breaker.
Use class CC or T fast-acting current-limiting type fuses, 200,000 AIC,
preferred. Use Bussmann KTK-R, JJN, JJS or equivalent. Thermal-magnetic type
breakers preferred. The following fuse examples and Allen-Bradley circuit
breakers are recommended for use with Kinetix 350 drives.
Figure 2 - Fuse and Circuit Breaker (CB) Specifications
Drive Cat. No.
Drive
Voltage
Phase
UL Applications IEC (non UL) Applications
Fuses
(Bussmann)
Miniature CB
(1)
Cat. No.
Motor Protection CB
(1)(2)
Cat. No.
DIN gG Fuses
Amps, max
Miniature CB
(1)
Cat. No.
Motor Protection CB
(1)
Cat. No.
2097-V31PR0-LM
120V
Single-phase
(voltage doubler)
KTK-R-20 (20 A) 1489-A1C200 140M-D8E-C20 20 1492-SP1D200 140M-D8E-C20
120/240V Single-phase KTK-R-10 (10 A) 1489-A1C100 140M-C2E-C10 10 1492-SP1D100 140M-C2E-C10
2097-V31PR2-LM
120V
Single-phase
(voltage doubler)
KTK-R-30 (30 A) 1489-A1C300 140M-F8E-C32 32 1492-SP1D300 140M-F8E-C32
120/240V Single-phase KTK-R-20 (20 A) 1489-A1C200 140M-D8E-C20 20 1492-SP1D200 140M-D8E-C20
2097-V32PR0-LM
240V Single-phase
KTK-R-15 (15 A) 1489-A1C150 140M-D8E-C16 16 1492-SP1D150 140M-D8E-C16
2097-V32PR2-LM KTK-R-20 (20 A) 1489-A1C200 140M-D8E-C20 20 1492-SP1D200 140M-D8E-C20
2097-V32PR4-LM KTK-R-30 (30 A) 1489-A1C300 140M-F8E-C32 32 1492-SP1D320 140M-F8E-C32
2097-V33PR1-LM
120/240V Single-phase KTK-R-20 (20 A) 1489-A1C200 140M-D8E-C20 20 1492-SP1D200 140M-D8E-C20
240V Three-phase KTK-R-15 (15 A) 1489-A3C150 140M-D8E-C16 16 1492-SP3D150 140M-D8E-C16
2097-V33PR3-LM
120/240V Single-phase KTK-R-20 (20 A) 1489-A1C200 140M-D8E-C20 20 1492-SP1D200 140M-D8E-C20
240V Three-phase KTK-R-15 (15 A) 1489-A3C150 140M-D8E-C16 16 1492-SP3D150 140M-D8E-C16
2097-V33PR5-LM
120/240V Single-phase KTK-R-30 (30 A) 1489-A1C300 140M-F8E-C32 32 1492-SP1D300 140M-F8E-C32
240V Three-phase KTK-R-20 (20 A) 1489-A3C200 140M-D8E-C20 20 1492-SP3D200 140M-D8E-C20
2097-V33PR6-LM
120/240V Single-phase LPJ-40SP N/A
140M-F8E-C32
40 N/A
140M-F8E-C32
240V Three-phase KTK-R-30 (30 A) 1489-A3C300 32 1492-SP3D300
2097-V34PR3-LM
480V Three-phase
KTK-R-10 (10 A) 1489-A3C100 140M-C2E-C10 10 1492-SP3D100 140M-C2E-C10
2097-V34PR5-LM KTK-R-10 (10 A) 1489-A3C100 140M-C2E-C10 10 1492-SP3D100 140M-C2E-C10
2097-V34PR6-LM KTK-R-20 (20 A) 1489-A3C200 140M-D8E-C20 20 1492-SP3D200 140M-D8E-C20
(1) Bulletin 1492 circuit protection devices have lower short-circuit current ratings than Bulletin 140M devices. Refer to http://ab.rockwellautomation.com/allenbradley/
productdirectory.page? for product literature with specific short-circuit ratings.
(2) For UL applications, Bulletin 140M devices are applied as self-protected combination motor controllers.
