6-1
DIAGNOSTICS & TROUBLESHOOTING
DISPLAY FAULT / ERROR CODES
DISPLAY
(Saved Code)
EXPLANATION AND RECOMMENDED PROCEDURE
(F30)
Long Fill
LF flashes when the water level does not change for a period of time on OR water is present but control does not detect
the water level changing.
• Is water supply connected and turned on?
•
Are hose screens plugged?
• Is water water siphoning out of the drain hose? Check for proper drain hose installation.
• Is the pressure hose connection from the tub to the machine/motor control pinched or plugged?.
• See TEST #2.
(F32)
Long Drain
Ld flashes when the water level does not change after the drain pump is on.
• Is the drain hose or the drain pump clogged?
• Is the drain hose height greater than 96˝ ?
• Is the pressure hose connection from the tub to the machine/motor control pinched or plugged?
• Is the pump running? If not, see TEST #7.
(none)
Unbalanced Load
uL is displayed when the machine/motor control detects an off-balance load, and is steady on while the washer runs a
mini-cycle to rebalance the load.
• Display clears if mini-cycle successfully rebalanced the load.
• If the mini-cycle is unsuccessful, uL will flash until the door lid is opened, allowing the customer to view and redistribute
the load.
(F70)
Overloaded
oL flashes when the machine/motor control detects a load size that exceeds the washer’s capacity OR basket can not
disengage. This may signify:
• Load size exceeds washer capacity. Remove excess laundry, then restart cycle.
• Mechanical friction on drive mechanism, mot allowing the basket to disengage.
(F71)
Suds Detection
Sd is displayed when the machine/motor control, by analyzing drag on the basket, detects a suds-lock condition, and is steady
on while the control then runs a mini-clean out cycle. If the clean out cycle is unable to correct the over-sudsing problem, the
cycle ends and Sd flashes in the display. This may signify:
• Excessive detergent usage.
• Load is bunched or twisted around agitator.
• Basket cannot engage during drain step.
• Mechanical friction on drive mechanism, not allowing basket to engage.
Continued on the next page.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
WARNING
