Installation
21
510975
Reversing Door Procedure
NOTE: Doors with windows cannot be reversed.
The door on this dryer is completely reversible. To
reverse door proceed as follows:
D675I
1
Remove four hinge
attaching screws.
D675S
D311S
2
Remove all nine
screws.
D311S
B
A
D312S
3
Pull bottom of door
liner out, then pull
down, removing
door liner from
door panel.
D312S
D313S
4
Rotate door panel
180 degrees as
shown.
D313S
D314S
5
Remove door strike
from door liner and
reinstall on opposite
side.
D314S
D315S
A
B
6
Insert liner under
flange on bottom of
door, then push top
of door liner into
place.
D315S
D316S
7
Reinstall nine
screws removed in
step 2.
D316S
D317S
8
Using a screwdriver,
remove two door
plugs, and reinstall on
opposite side of door
opening.
D317S
D606I
Reinstall four hinge
attaching screws
removed in step 1.
9
D606I
