© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
510975
12
Coin Slide Guards
(Metered Models)
Using sheet metal screws from accessories bag
(located in lower cylinder), install coin slide guards
(located in accessories bag in lower cylinder) to front
of dryer’s control cabinet. Refer to Figure 2.
Figure 2
NOTE: Coin slides and coin drawers are shown for
illustration only. You must obtain them locally.
D784I
1 Coin Slide Guard 2 Sheet Metal Screws
PUSH TO START
IN USE
IN USE
PUSH TO START
FABRIC SELECTOR
FABRIC SELECTOR
PERM PRESS
NORMAL
DELICATE
FLUFF
(NO HEAT)
PERM PRESS
NORMAL
DELICATE
FLUFF
(NO HEAT)
D784I
2
2
1
1
