© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
510975
10
Nonmetered Models
NOTE: Side, rear and bottom exhaust openings are
4" (10.2 cm) ducting. Gas models cannot be vented
out left side of cabinet because of burner housing.
IMPORTANT: The dryer should have sufficient
clearance around it for needed ventilation and for
the ease of installation and servicing. For maximum
drying performance, we recommend that more
clearance be allowed around the dryer than the
clearances that are listed throughout this manual.
DRY50N
*With leveling legs turned into base.
7"
(17.8 cm)
*76.5" (194.3 cm)
*44.8" (113.8 cm)
23.5"
(59.7 cm)
8"
(20.3 cm)
4"
(10.2 cm)
26.9"
(68.3 cm)
15.5"
(39.4 cm)
28.0"
(71.1 cm)
ELECTRIC MODELS
4.5"
(11.4 cm)
DRY51N
*With leveling legs turned into base.
1 3/8" N.P.T. Gas Connection
7"
(17.8 cm)
*76.5" (194.3 cm)
*44.8" (113.8 cm)
23.5"
(59.7 cm)
4"
(10.2 cm)
26.9"
(68.3 cm)
15.5"
(39.4 cm)
28.0"
(71.1 cm)
GAS MODELS
*43.5" (110.5 cm)
2.8"
(7.1 cm)
8"
(20.3 cm)
1
4.5"
(11.4 cm)
2.3"
(6 cm)
