Each of the trunk cards was designed to fit a specific system need. Use
Table 7 to help select the trunk card that will best meet system needs.
NT8D14 Universal Trunk card
The NT8D14 Universal Trunk card is an intelligent four-channel trunk card
that is designed to be used in a variety of applications. It supports the
following five trunk types:
• Central office (CO), Foreign Exchange (FEX), and Wide Area
Telephone Service (WATS) trunks
• Direct Inward Dial (DID) trunks
• TIE trunks: two-way Loop Dial Repeating (LDR) and two-way loop
Outgoing Automatic Incoming Dial (OAID)
• Recorded Announcement (RAN) trunks
• Paging (PAG) trunks
Table 7
Trunk card characteristics
Part
Number
Description Trunks Trunk Types Architecture
NT8D14 Universal Trunk card 8 CO/FX/WATS trunks*,
direct inward dial trunks,
TIE trunks,
Loop Dial Repeating trunks
Recorded Announcement
trunks,
Paging trunks
IPE
NT8D15 E&M Trunk card 4 2-wire E&M trunks,
4-wire E&M trunks,
4-wire DX trunks,
Paging trunks
IPE
NTCK16 Generic Central Office
Trunk card
8 CO trunks IPE
* Central office (CO), Foreign Exchange (FX), and Wide Area Telephone Service (WATS) trunks.
