Page 540 of 906 NT8D02 and NTDK16 Digital Line cards
553-3001-211 Standard 3.00 August 2005
16A Line 4, Ring 16B Line 4, Tip
17A Line 5, Ring 17B Line 5, Tip
18A Line 6, Ring 18B Line 6, Tip
19A Line 7, Ring 19B Line 7, Tip
62A Line 8, Ring 62B Line 8, Tip
63A Line 9, Ring 63B Line 9, Tip
64A Line 10, Ring 64B Line 10, Tip
65A Line 11, Ring 65B Line 11, Tip
66A Line 12, Ring 66B Line 12, Tip
67A Line 13, Ring 67B Line 13, Tip
68A Line 14, Ring 68B Line 14, Tip
69A Line 15, Ring 69B Line 15, Tip
Table 176
NT8D02 Digital Line card – backplane pinouts (Part 2 of 2)
Backplane
Pinout*
Lead
Designations
Backplane
Pinout*
Lead
Designations
* These pinouts apply to both the NT8D37 and NT8D11 backplanes
