Installing the Unit
Step 1:
Position Unit Near Installation Area
Move unit so that it is within four feet of the desired area
of installation.
Step 2:
Connect Water Inlet Hoses
NOTE: Refer to Section on Water Supply
Requirements before connecting water inlet hoses.
Remove the four plain rubber washers from accessories
bag, and install them according to the illustration.
Turn on the water supply faucets and flush the lines for
approximately two minutes to remove any foreign
materials that could clog the screens in the water mixing
valve.
NOTE: When installing in newly constructed or
renovated building, it is very important to flush the
lines since build-up may have occurred during
construction.
IMPORTANT: Thread hose couplings onto valve
connections finger-tight, then approximately 1/4 turn
with pliers. DO NOT cross thread or overtighten
couplings.
Turn water on and check for leaks. If leaks are found,
retighten the hose couplings. Continue tightening and
rechecking until no leaks are found.
. . .
Washer and dryer are not designed to be
operated as separated, side-by-side units.
W187
CAUTION
H243I
RUBBER WASHER
(Plain)
H091IE1A
INSTALL THIS
END OF HOSE
TO WATER
SUPPLY FAUCET
INSTALL THIS END OF HOSE
TO VALVE CONNECTIONS
AT REAR OF WASHER
INLET
HOSE
RUBBER WASHER
(Plain)
H096IE1A
WATER
SUPPLY
FAUCETS
WATER
INLET
HOSES
COLD WATER
CONNECTION
WATER
MIXING VALVE
HOT WATER
CONNECTION
