72 Chapter 4: Property Management

Property Data Types iTool Developer’s Guide

6 LINESTYLE Linestyle properties contain an integer value between 0

and 6, corresponding to the following IDL line styles:

• 0 = Solid

•1=Dotted

•2=Dashed

•3=Dash Dot

• 4 = Dash Dot Dot

• 5 = Long Dashes

• 6 = No Line

See Appendix B, “Property Controls” (iTool User’s

Guide) for a visual example of the available line styles.

7 SYMBOL Symbol properties contain an integer value between 0 and

8, corresponding to the following IDL symbol types:

• 0 = No symbol

•1=Plus sign

•2=Asterisk

• 3 = Period (Dot)

• 4 = Diamond

• 5 = Triangle

•6=Square

•7=X

• 8 = “Greater-than” Arrow Head (

>)

• 9 = “Less-than” Arrow Head (

<)

See Appendix B, “Property Controls” (iTool User’s

Guide) for a visual example of the available symbols.

Type

Code

Type Description

Table 4-1: iTools Property Data Types (Continued)
