12
CODE EXPLANA TION
OPTIONSTOUSE IFSPECIALPRICING IS SELECTED (cont.):
TIME-OF-DAY CLOCK, MINUTES
This is theTIME-OF-DAY CLOCK, minute setting;
select 0-59 minutesbypressing the LOWER LEFT key pad.
�
Press the LOWERMIDDLEkey pad oncetoadvance to next code.
TIME-OF-DAY CLOCK, HOURS
NOTE:Usesmilitarytimeor24hr. clock.
This is theTIME-OF-DAY CLOCK, hour setting; select 0-23 hours
by pressingthe LOWER LEFTkey pad.
�
Press the LOWERMIDDLEkey pad oncetoadvance to next code.
SPECIAL PRICE START HOUR
NOTE:Usesmilitarytimeor24hr. clock.
This is thestart hour; 0-23hours.SelectSTART HOURbypressing
theLOWER LEFT key pad.
Press theLOWER MIDDLE key pad oncetoadvance to next code.
�
Press the LOWERMIDDLEkey pad oncetoadvance to next code.
SPECIAL PRICE STOP HOUR
NOTE:Usesmilitarytimeor24hr. clock.
This is thestophour; 0-23 hours.Select STOP HOURbypressing
theLOWER LEFT key pad.
�
Press the LOWERMIDDLEkey pad oncetoadvance to next code.
SPECIAL PRICEDAY
This represents theday of the weekand whether special pricing
is selected forthatday .Anumber followed by ‘0’ indicates no
selectionthatparticular day (9.10).A number followedbyan ‘S’
indicatesselected for that day (9.1S).
Days of the week (1-7) can be chosen by pressing the LOWER
LEFT keypad.Press theLOWER LEFTkey pad once to select
.special pricing for each daychosen.
When exiting set-up code ‘9’,the display must show current day
of week:
DISPLAYDAY OF WEEK CODE (selected)
10 Day1=Sunday1S
20 Day2=Monday2S
30 Day3=Tuesday3S
40 Day4=Wednesday 4S
50 Day5=Thursday 5S
60 Day6=Friday6S
70 Day7=Saturday7S
�
Press theLOWER MIDDLE keypad once to advance to next code.
8. 00
8. 00
9. 10
9. 10
VAULTVIEWING OPTION
This option is eitherSELECTED ‘ON’ or NOT SELECTED ‘OFF’.
Not Selected ‘OFF’.
Selected ‘ON’.Press theLOWER RIGHT key pad once for
this selection.Whenselected,the money and/or cycle counts
will be viewable (if counting is selected) when the coin
boxis removed.
�
Press theLOWER MIDDLE key pad oncetoadvance to next code.
VALUEOFCOIN 1
This represents thevalue of coin 1in number of nickels:
05 = $0.25.
By pressing theLOWER LEFTkey pad,youhavethe option
of 1-199 nickels.
�
Press theLOWER MIDDLE key pad oncetoadvance to next code.
A.
00
A.
00
6. 05
6. 05
A.SC
5. 00
5.00
6. 00
6.00
7. 00
7. 00
CODE EXPLANA TION
VALUEOFCOIN2
This represents the valueofcoin2in numberofnickels:
20 =$1.00.
PR MODELS ONLY:Factory presetfor $0.25.
By pressingthe PERMANEN TPRESS keypad, you have the option
of 1-199 nickels.
�
Press the LOWER LEFTkey padoncetoadvance to next code.
COIN SLIDE OPTION
This option is either SELECTED ‘ON’ or NOT SELECTED‘OFF’.
Not Selected ‘OFF’.
Selected‘ON’. Pressthe LOWER RIGHTkey pad 3consecutive
times forthis selection.
Whencoin slide mode is selected, set‘b.’ equal to valueof slide
in nickels. Se tstep 6(regular cycleprice) and step 3 (specia lcycle
price)tonumber of slideoperations.Ifthe installer sets up ‘CS’
onacoin drop model, it will not register coins .
�
Press the LOWER MIDDLE keypad once to advance to next code.
ADDCOINS OPTION
This option is either SELECTED ‘ON’ or NOT SELECTED ‘OFF’.This
optioncauses thecustomer display to show the number of coins
(coin1)toenter, rather than the dollars-and-cents amount.
Not Selected ‘OFF’.
Selected‘ON’. Pressthe LOWER RIGHTkey pad
3consecutivetimes for thisselection.
�
Press the LOWER MIDDLE keypad once to advance to next code.
ENHANCEDPRICING OPTION
Not Selected ‘OFF’.
Cycle-Based pricing enabled.This optionallows configuration
of different pricesfor cold,warm, and hotwater cycles. Press the
LOWER RIGHT key padfor this selection.
Super Cyc le pricing enabled.This optionallows customers
to upgrade cycles by depositing extra money. Set-up codes
‘H.’ and‘h.’willbe displaye donly when this option is enabled.
Press the LOWER RIGHTkey pad for this selection.
�
Press the LOWER MIDDLE keypad once to advance to next code.
SUPER CYCLE UPGRADE PRICE
(SkippedunlessSuper Cyclepricing is enabled.)
This represents the numberofcoin 1 required to upgrade a
basecycle to asuper cycle.Advance from 0-39 by pressing
theLOWER LEFTkey pad.
�
Press the LOWER MIDDLE keypad once to advance to next code.
SUPER CYCLE TYPE
(SkippedunlessSuper Cyclepricing is enabled.)
This represents the Super Cycle upgrade option. Press the
LOWER LEFT key padto step through upgrade options1
through 3asfollows:
01 -enhanced wash,extra 3 minutesof wash tumble in addition
to theprogrammed wash time.
02 -extra rinsefor allcycles.
03 -both01and 02.
�
Pressthe LOWER MIDDLE keypad once to advance to next code.
8.00
E
.00
E
.00
E
.
AC
8.00
8.
CS
F
.00
F
.00
F
.
CP
F
.
S
8
H
.0 1
H
.0 1
H
.0 1
H
.0 1
C
.20
C
.20
