Programming Hints
Read the preprogrammed cycle charts (near the end of
this manual) for the cycles already programmed into
the computer to see how the cycle steps have been
ordered.
Use a program worksheet, such as the sample on the
next page, to write new cycles. After the worksheet is
completed, enter the program into the computer.
The computer can do only one thing at a time, so think
in terms of what the machine should do next, step by
step. This will make it simpler to write the program.
When entering the timed portion of a step (such as a
fill), use a time that is reasonable for the local
installation. If the water pressure is low or if the water
lines are smaller than desirable, increase the time
allowed. Remember that the drain needs to empty the
machine in less than one minute. Drain times of more
than one minute are not recommended.
Except for the soak, heat, and cool-down (Wash 5)
steps, which are timed in hours and minutes, the
maximum time per step is 9 minutes and 99 seconds. If
more time is needed, add more steps to total the
complete time desired. For example, if a 15-minute
wash is desired, program a wash step for 9 minutes
and 00 seconds, immediately followed by another
wash step for 6 minutes and 00 seconds.
When a fill or addition of supplies without agitation is
desired, first program a Wash 3 step for 0 minutes and
01 seconds. Then program the fill or supply step.
When the microcomputer advances to the next step, it
will remain in the wash mode as programmed in the
previous step unless it is instructed to do otherwise.
Before attempting to program any particular function
of the WE-6 microcomputer, read the System
Programming, Cycle Programming, and Step
Programming subsections below.
CYCLE 00
Step Description Min:sec
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
