Error & Status Messages on the Control Panel
55
5
Hardware Problem
Option RAM
The printer identified an op-
tional RAM error.
Turn the power off, and then on. Re-
move and re-install the optional RAM.
If the message appears again, contact
your sales or service representative.
See “Attaching Memory Unit Type C
256MB (SDRAM Module)”, Setup
Guide.
Turn off the power, remove the mem-
ory unit, and then turn on the power.
Note
❒ If you remove the memory unit,
you must set up the option with
the printer driver.
❒ In this case, you might not be able
to print complex print jobs.
Hardware Problem
Parallel I/F
There is a problem with the
parallel interface.
If you use the parallel I/F, replace the
interface cable that caused the error. If
the message appears again, contact
your sales or service representative.
Hardware Problem
USB
There is a problem related to
the Universal Serial Bus Con-
nection and Hardware.
Turn the power off, and then on. If the
message appears again, contact your
sales or service representative.
Hardware Problem
Wireless Board
An error was detected in the
IEEE 802.11b interface unit or
the Bluetooth interface unit.
Turn the power off, and then on. Re-
move and re-install the IEEE 802.11b
interface unit or the Bluetooth inter-
face unit correctly.
If the message appears again, contact
your sales or service representative.
See “ Attaching 802.11b Interface Unit
Type F ” or “Attaching Bluetooth In-
terface Unit Type C ”, Setup Guide.
Hardware Problem
Wireless Card
The IEEE 802.11b interface unit or
the Bluetooth interface unit could
not be detected when the power
was turned on. The IEEE 802.11b
interface card or the Bluetooth in-
terface card was removed after
the power was turned on. An er-
ror was detected in the IEEE
802.11b interface card or the Blue-
tooth interface card.
Turn the power off, and then on. Re-
move and re-install the IEEE 802.11b
interface unit or the Bluetooth inter-
face unit correctly.
If the message appears again, contact
your sales or service representative.
See “ Attaching 802.11b Interface Unit
Type F ” or “Attaching Bluetooth In-
terface Unit Type C ”, Setup Guide.
HDD Full
The maximum HDD area size for
form/font has been exceeded.
Delete the disused form/font types.
The optional Hard Disk Drive is
full. The sample print job or
locked print job to be sent from
the computer is too large to store.
Delete any unnecessary stored files.
Messages/Second
messages
Description Solution
