Cleaning the Paper Feed Roller
45
3
Cleaning the Paper Feed Roller
If the paper feed roller is dirty, a mis-
feed might occur. In this case, clean
the roller as follows:
CAUTION:
Important
❒
The following are examples of clean-
ing the paper feed roller on the pa-
per tray.
❒ You can clean the paper feed roller
on the optional paper feed unit by
following the procedures below.
The paper feed roller on the op-
tional paper feed unit differs from
the one on the paper tray. Confirm
the type of paper feed roller you
are installing.
A For the paper tray
B For the paper feed unit
A Turn off the power.
B Pull out the plug from the socket.
Remove all the cables from the
printer.
C Lift the paper tray slightly, and
then pull it out until it stops. Lift
the front side of the tray, and then
pull it out of the printer.
D Move the printer to the edge of a
stable table or desk.
Important
❒ Do not put the printer on an un-
stable or tilted surface.
❒ If the printer is equipped with
the optional paper feed unit, do
not move the printer and unit
together as they are not securely
attached.
❒ When lifting the printer, con-
firm that the optional paper
feed unit is not attached to the
printer.
• When lifting the printer, use the
grips on both sides of the printer,
otherwise the printer might fall
and cause personal injury.
• When you move the printer, un-
plug the power cord from the wall
outlet to avoid a fire or an electric
shock.
• When you pull out the plug from
the socket, grip the plug to avoid
damaging the cord and causing
a fire or an electric shock.
AGN017S
ZKGY140E
AGN021S
