504 766 PUBLICATION DATE 03/02 INSTALLATION AND MAINTENANCE MANUAL 7
1-Motor version 2-Motor version
CAPACITY: 33kg / 75lbs
WASHING FUNCTION
RPM OF THE DRUM:
washing
distribution
low spinning
high spinning
7 - 50 rpm
90 rpm
301 - 830 rpm
36 rpm
59 rpm
435 rpm
845 rpm
G - factor of spinning max. 365 365
HEATING
Types of heating: steam
100 % electric 24 kW
100 % hot water max 90°C / 194°F
ATTACHMENT
OF WATER INLETS:
water pressure
water inlet
0,3 - 0,6 MPa / 44 - 87 PSI
1“
OF WATER DRAINAGE:
dimension
capacity
2 x ∅76 mm / 2 x ∅ 3“
300 dm
3
/min / 80 US gal/min
OF STEAM HEATING:
steam attachment
steam pressure
3/4“
0,3 - 0,8 MPa / 44 - 116 PSI
COMPRESSED AIR:
air connection
air pressure
G 1/4“
0,3 - 0,8 MPa / 44 - 116 PSI
Connections to external liquid soap supply system 1 connection for manifold
(1 - 5, 6 - 10, ... connections) to liquid soap supply
system
Soap hoppers: 5
CONSUMPTION
Mean water consumption: depends on selected programme cca 900 dm
3
/
240 US gal
STEAM CONSUMPTION:
depends on selected programme
Maximum steam consumption
33 kg. cycle
-1
/ 72,77 lbs. cycle
-1
0,046 kg.s
-1
(165 kg.h
-1
) / 0,101 lbs.s
-1
(364 lbs.h
-1
)
WORKING CONDITIONS
ambient temperature
mean ambient temperature in 24 hrs
relative humidity
height above sea level
from +5°C / 41°F to +40°C / 104°F
to +35°C / 95°F
30% ÷ 95% without condensation
to 1000 m
ANCHORING
Bolt: 4 pcs M16
max. static loading (with linen and water)
max. dynamic loading
(alternative stress when extracting)
frequency of dynamic loading
1597kg / 3521lbs
± 280kg / ± 618lbs
14 Hz
NOISE
Equivalent noise level at spinning cycle L
Aeq
: 80,8 dBA
Level of acoustic output L
P,A
: 84,7 dB (P,A)
maximum dimensions including protruding parts
it is valid for machines, which have water valves with air operated control
tab. 3.2 continuation
*
*
*
*
*
