Roughing In Dimensions . . .
(Metered Models)
NOTE: Side, rear and bottom exhaust openings are
four inch (10.2 cm) ducting. Gas models cannot be
vented out left side of cabinet because of burner
housing.
IMPORTANT: The dryer should have sufficient
clearance around it for needed ventilation and for the
ease of installation and servicing. For maximum
drying performance, we recommend that more
clearance be allowed around the dryer than the
clearances that are listed throughout this manual.
ELECTRIC MODELS
D350IE2A
28.0"
(71.1 cm)
26.9"
(68.3 cm)
23.5"
(59.7 cm)
4.0"
(10.2 cm)
*76.5" (194.3 cm)
*45.2" (114.8 cm)
15.4"
(39.1 cm)
7.7"
(19.6 cm)
7.0"
(17.8 cm)
4.0"
(10.2 cm)
* WITH LEVELING LEGS TURNED INTO BASE.
GAS MODELS
D351IE2A
28.0"
(71.1 cm)
26.9"
(68.3 cm)
23.5"
(59.7 cm)
4.0"
(10.2 cm)
*76.5" (194.3 cm)
*45.2" (114.8 cm)
*WITH LEVELING LEGS TURNED INTO BASE.
15.4"
(39.1 cm)
7.7"
(19.6 cm)
7.0"
(17.8 cm)
4.0"
(10.2 cm)
2.8"
(7.1 cm)
43.5" (110.5 cm)
2.3"
(6 cm)
3/8"
NPT GAS
CONNECTION
