Installing the Dryer . . .
STEP 1:
Position and Level
the Dryer Unit
For further assistance refer to Section on Location
Requirements.
Install dryer before washer. This allows room for
attaching exhaust duct.
Install the four rubber cups found in the accessory bag.
Place the dryer in position, and adjust the legs until the
dryer is level.
STEP 2:
Connect Dryer Unit Exhaust System
For further assistance refer to Sections on Location
Requirements and Dryer Exhaust Requirements.
• DO NOT use plastic or thin foil flexible ducting.
• Locate dryer so exhaust duct is as short as possible.
• Be certain old ducts are cleaned before installing your
new dryer.
• Use 4" (10.2 cm) diameter rigid or flexible metal duct.
• Use as few elbows as possible.
• Use duct tape on all joints.
• Failure to exhaust dryer properly will void
warranty.
NOTE: Venting materials are not supplied with the
dryer (obtain locally).
D355IE1A
DRYER
BASE
LEVELING
LEG
RUBBER
CUP
A clothes dryer produces combustible lint. To
reduce the risk of fire and combustion gas
accumulation the dryer MUST be exhausted to
the outdoors.
WARNING
DON'T
D356IE0B
D354IE0C
DO
(continued)
)
