Programming
25
F232179
NOTE: ON appears ONLY where motor control
outputs are on (otherwise they are off). Outputs
referenced are on control unit fuse board. Outputs
are as labeled on the fuse board.
NOTE: For variable-speed machines smaller than
C80, SPn1 and SPn2 are not the same speed.
Table 4 (Continued)
Control Test
Pause 5 seconds, then Reverse
wash speed – 60 seconds, pause
several seconds before entering
drain (next step)
Display shows ‘rEv’
Outputs: Motor operates wash speed reverse; drain closed
Drain (cannot advance to spin
here)
For 2 speed models
: Display flashes “drAI”/“For” (keypad RINSE LED on)
For variable-speed models
: Display flashes “drAI”/“For” while operating in low speed
forward; then flashes “drAI”/“dISt” while operating at distribution speed.
If balance fails, repeats the “drAI”/“For” then “drAI”/“dISt” sequence above and balance
indicator is on during “drAI”/“For” message (rebalance attempt). Tries up to 10 times in
TEST cycle, then aborts test cycle.
Outputs: Drain closed for first part of step (less than 20 seconds), then drain off.
2 speed models
: Wash speed forward
Variable-speed
: Forward during “drAI”/“For”; distribution during “drAI”/“dISt”.
Spin: 2 minutes Certain models display “SPIn” (keypad SPIN LED on)
while other models display shows “SPn1” (keypad SPIN LED on)
Outputs: Spin (low spin for variable-speed – refer to motor chart below)
Highest Spin speed (Variable-
speed models ONLY):
2 minutes
For 2 speed models
: this step is skipped, goes to coast (the next step)
For variable-speed models
: display shows “SPn2” (keypad SPIN LED on) or “HI”
Outputs: Highest spin speed selected (refer to motor chart below)
Coast Displays “SdLY” (spin delay coast)
Outputs: All off
Stop routine Display shows “01” (1 minute remaining). Agitates briefly then unlocks the door, shows
“dOnE” while sounding the buzzer 10 seconds; “dOnE” shows for 20 more seconds.
(DOOR LED on while showing “dOnE”, meaning “door ready to open”).
Motor Speed Chart
Variable-speed Motor Control
Outputs
Fixed-speed and
2 Speed Motor
Outputs
STF STR RH RM RL Fwd Rev Spin
Motor off (no rotation)
Wash speed forward ON ON ON
Wash speed reverse ON ON ON
Distribution (variable-speed ONLY) ON ON NA NA NA
Spin (low spin speed “SPn1” for variable-speed) ON ON ON ON
Highest spin (“SPn2” – variable-speed ONLY) ON ON ON NA NA NA
NA – Not Applicable
Table 4
