Programming
F232179
14
Table 1 (Continued)
Cycle Steps Available
(NOTE: WASH, ADD BLEACH,
RINSE and SPIN LEDs light ONLY
when a cycle formula is in
operation.)
Display Setting Options for Cycle Steps
Wash 4 (displayed as “USH4”)
Heat (Models with heat or heat capability) HEAt 00F (no heat for segment) or 80
o
F to 205
o
F
00C (no heat for segment) or 27
o
C to 95
o
C
noHt
Drain (Final segment drains in stop
routine if No Drain is programmed)
drAI Drain or No Drain (if No Drain programmed, will skip spin
segment associated with Drain segment)
nodr
Spin time SPIn 00 for No Spin or 30-240 seconds (increases/decreases in
one-second increments)
tInE
Rinse 1 (displayed as “rIN1”)
Time for Agitation (excludes fill, drain,
spin and heat)
nor
n 0 or 2-15 minutes in agitation step (increases/decreases in
one-minute increments). Refer to Table 3 for operation of
each agitation segment
GEnt
Fill valves (temperature) CFIL Cold, Hot or Both (warm) water fills or Extra Fill*
HFIL
bFIL
EFIL
Fill water level control LO Low, Medium or High water level
nEd
HI
Supply SUP0 SUP0 for No Supply or Supply 1- 7 (Refer to Table 2 for
operation of each supply selection)
SUP1
SUP2
SUP3
SUP4
SUP5
SUP6
SUP7
Heat (Models with heat or heat capability) HEAt 00F (no heat for segment) or 80
o
F to 205
o
F
00C (no heat for segment) or 27
o
C to 95
o
C
noHt
Drain (Final segment drains in stop
routine if No Drain is programmed)
drAI Drain or No Drain (if No Drain programmed, will skip spin
segment associated with Drain segment)
nodr
Spin time SPIn 00 for No Spin or 30-240 seconds (increases/decreases in
one-second increments)
*Extra Fill (EFIL) possible only if international model configured for “EFIL” in SETUP mode.
