Programming
11
F232179
Options for Each Segment
Cycle Steps Available
(NOTE: WASH, ADD BLEACH,
RINSE and SPIN LEDs light ONLY
when a cycle formula is in
operation.)
Display Setting Options for Cycle Steps
Wash 1 (displayed as “USH1”)
Time for Agitation (excludes fill, drain,
spin and heat)
nor
n 0 or 2-30 minutes in agitation step (increases/decreases in
one-minute increments). Refer to Table 3 for operation of
each agitation segment
GEnt
Fill valves (temperature) CFIL Cold, Hot or Both (warm) water fills or Extra Fill*
HFIL
bFIL
EFIL
Fill water level control LO Low, Medium or High water level
nEd
HI
Supply SUP0 SUP0 for No Supply or Supply 1- 7 (Refer to Table 2 for
operation of each supply selection)
SUP1
SUP2
SUP3
SUP4
SUP5
SUP6
SUP7
Heat (Models with heat or heat capability) HEAt 00F (no heat for segment) or 80
o
F to 205
o
F
00C (no heat for segment) or 27
o
C to 95
o
C
noHt
Drain (Final segment drains in stop
routine if No Drain is programmed)
drAI Drain or No Drain (if No Drain programmed, will skip spin
segment associated with Drain segment )
nodr
Spin time SPIn 00 for No Spin or 30-240 seconds (increases/decreases in
one-second increments)
tInE
Wash 2 (displayed as “USH2”)
Time for Agitation (excludes fill, drain,
spin and heat)
nor
n 0 or 2-20 minutes in agitation step (increases/decreases in
one-minute increments). Refer to Table 3 for operation of
each agitation segment
GEnt
Fill valves (temperature) CFIL Cold, Hot or Both (warm) water fills or Extra Fill*
HFIL
bFIL
EFIL
*Extra Fill (EFIL) possible only if international model configured for “EFIL” in SETUP mode.
Table 1 (Continued)
