6
SECTION III
OPERATING INSTRUCTIONS
A. COIN MODE
1. When at least one (1) of the dryer’s pockets is in the ready state and no cycle is in progress, the liquid crystal
display (L.C.D.) screen will display a ready prompt depending on the READY PROMPT option in PL #01.
If the option is set to “READY, INSERT AMOUNT TO START” the display will read “READY, INSERT
$XX.XX TO START.” If the READY PROMPT option in PL #01 is set to “READY” the display will read
“READY”. If both pockets are idle, both sections of the L.C.D. will display the selected READY PROMPT
message.
2. Insert coin(s). Once the correct “AMOUNT TO START” has been inserted, the pocket will now display
“SELECT TEMP TO START.” If the other pocket was already in a cycle, that pocket will display “SELECT
TEMP TO ADD TIME.” If both pockets were idle, both pockets will display “SELECT TEMP TO START.”
3. Select temperature by pressing “HI” , “MED” , or “LO” on the dryer pocket you wish to start the
cycle in. The cycle will start, and the L.C.D. will display the Dry Cycle selected and the remaining time.
4. The dryer will continue through the drying and cooling cycles until the vended time has expired.
5. In Coin Mode, if more time is desired the customer will have to insert more credit. The Phase 7 dual
microprocessor controller (DMC) computer will vend the additional time according to the configured Coin
Mode. If the Phase 7 DMC (computer) is set to Accumulative Time, each coin inserted will yield some
additional drying time. Once a coin is inserted any pocket that is idle will display “SELECT TEMP TO
START” and any cycle that is in progress will display “SELECT TEMP TO ADD TIME”. In Accumulative
Coin Mode, the Phase 7 DMC (computer) will only vend additional drying time after the amount for top off
has been met. In Accumulative Coin Mode, if a coin is inserted into the dryer, which does not meet the
amount for top off the Phase 7 DMC (computer) will prompt the user to add more credit for more time.
Once the AMOUNT FOR TOP OFF is inserted any pocket that is in progress will display “SELECT
TEMP TO ADD TIME.” If the AMOUNT FOR TOP OFF is less than the AMOUNT TO START the
Phase 7 DMC (computer) will prompt for more credit in any pocket that is idle. If the AMOUNT FOR
TOP OFF is more than the AMOUNT TO START the control will display “SELECT TEMP TO START”
in any pocket that is idle. More information on Accumulative Time and Accumulative Coin can be found on
page 18 through page 21 under PL #06 VENDING PARAMETERS – VENDING MODE.
6. Upon completion of drying and cooling cycles the buzzer will sound, and the dryer will go into Wrinkle
Guard Mode for 99 minutes or until the door has been opened.
B. FREE MODE
1. When the Phase 7 DMC (computer) is in the ready state and no cycle is in progress, the L.C.D. screen will
display “SELECT TEMP TO START.”
2. Select temperature by pressing “HI” , “MED” , or “LO” . The cycle will start and the Phase 7
DMC (computer) will display the Dry Cycle selected and the remaining time.
