ACCUMULATIVE COIN
In Accumulative Coin Mode, additional time can only be achieved when the AMOUNT FOR TOP OFF
(PL #06) has been inserted.
If a coin is inserted into the dryer, which is less than the AMOUNT FOR TOP OFF the Phase 7 dual microprocessor
controller (DMC) computer will prompt the user to add more credit for more time with the following message
“ADD XX FOR ADDITIONAL TIME”. The Phase 7 DMC (computer) will scroll this message for 30-seconds
and then will return to the normal drying cycle information. The credit that was just inserted
will be kept in
escrow until more credit is inserted to meet the AMOUNT FOR TOP OFF, or the cycle finishes. In the event that
the cycle finishes, any credit that was left in escrow
will now be applied to the next cycle. Below are examples of
different scenarios in Accumulative Coin Mode.
Single Coin Acceptor
Example No. 1: If the dryer is equipped with a 25¢ coin acceptor and the AMOUNT TO START (PL #06) is
50¢, AMOUNT FOR TOP OFF (PL #06) is 50¢, the HI key TIME FOR AMOUNT TO
START (PL #03) is 24 minutes, and the HI key TIME FOR TOP OFF (PL #03) is 12 minutes.
The initial first two (2) coins will yield 24 minutes and each additional two (2) coins entered
into the dryer will yield 12 minutes; no time will be vended if only one (1) coin is inserted.
Settings: PL #06 (LEFT COIN DENOMINATION) ....................... 25
PL #03 (TIME FOR AMOUNT TO START) ................... 24
PL #03 (TIME FOR TOP OFF)......................................... 12
PL #06 (AMOUNT TO START)........................................ 50
PL #06 (AMOUNT FOR TOP OFF) ................................. 50
Formula: (AMOUNT TO START [PL #06]) = Vended Time is TIME FOR AMOUNT TO START (PL #03)
50¢ = 24 minutes
(AMOUNT FOR TOP OFF [PL #06]) = Vended Time is TIME FOR TOP OFF (PL #03)
50¢ = 12 minutes
Example No. 2: If the dryer is equipped with a 25¢ coin acceptor and the AMOUNT TO START (PL #06) is
50¢, AMOUNT FOR TOP OFF (PL #06) is 25¢, the MED key TIME FOR AMOUNT TO
START (PL #04) is 24 minutes, and the MED key TIME FOR TOP OFF is 12 minutes. The
initial first two (2) coins will yield 24 minutes and each additional coin entered into the dryer
will yield 12 minutes.
After the AMOUNT TO START (PL #06) has been met, each additional coin entered into the
dryer will yield 12 minutes.
Settings: PL #06 (LEFT COIN DENOMINATION) ....................... 25
PL #04 (TIME FOR AMOUNT TO START) ................... 24
PL #04 (TIME FOR TOP OFF)......................................... 12
PL #06 (AMOUNT TO START)........................................ 50
PL #06 (AMOUNT FOR TOP OFF) ................................. 25
Formula: (AMOUNT TO START [PL #06]) = Vended Time is TIME FOR AMOUNT TO START (PL #04)
50¢ = 24 minutes
(AMOUNT FOR TOP OFF [PL #06]) = Vended Time is TIME FOR TOP OFF (PL #04)
25¢ = 12 minutes
