71
3. Bottom Pocket Inputs
LINT – (RED L.E.D.) This light emitting diode (L.E.D.) will indicate the status of the lint drawer.
If the drawer is closed, then the L.E.D. is ON.
EXHL – (RED L.E.D.) This L.E.D. will indicate the status of the exhaust high limit disk. If the disk
is closed (temperature below 225º F [107º C]), then the L.E.D. is ON.
SAIL – (RED L.E.D.) This L.E.D. will indicate the status of the sail switch. If the switch is closed,
then the L.E.D. is ON.
GAS_V – (RED L.E.D.) This L.E.D. will indicate the status of the gas valve. If the gas valve is open
(ON), then the L.E.D. is ON.
MAIN – (RED L.E.D.) This L.E.D. will indicate the status of the main door. If the door is closed,
then the L.E.D. is ON.
FUSE – (RED L.E.D.) This L.E.D. should be on at
ALL times. If L.E.D. is off this will indicate
that fuse # F2 is blown.
BRHL – (RED L.E.D.) This L.E.D. will indicate the status of the burner high limit disk. If the disk is
closed (temperature below 330º F [166º C]), then the L.E.D. is ON.
4. Bottom Pocket Outputs
HEAT – (GREEN L.E.D.) This L.E.D. will indicate the status of the heat output. If the request to turn
on the heater is made, then the L.E.D. is ON.
DRIVE – (GREEN L.E.D.) This L.E.D. will indicate the status of the basket (tumbler) forward direction
output. If the request to tumble the basket (tumbler) in the forward direction
is made, then the L.E.D. is ON.
FAN – (GREEN L.E.D.) This L.E.D. will indicate the status of the fan output. If the request to turn
on the fan (blower) is made, then the L.E.D. is ON.
