Pressing and holding the “MED” key will show the temperature readings from ALL of the probes that is
equipped with the dryer.
ALL dryers will have an exhaust probe, the exhaust probe reading is always the first
temperature reading; if the exhaust probe is the only probe the dryer is equipped with, it will be the only temperature
reading shown. If the dryer is also equipped with a thermistor probe, this will be the second reading shown. If the
dryer is of an axial configuration and is equipped with an axial probe and thermistor probe, the temperatures
shown
will be exhaust probe on the left, axial probe in the middle and thermistor probe on the right. If the dryer
is equipped with an axial probe but no thermistor probe, the second temperature reading
will be that of the axial
probe.
Pressing and holding the “LO”
key will show the RPMs of the basket (tumbler).
The “PAUSE”
key will pause the dryer. If the dryer is paused, pressing the “HI” , “MED” , or “LO”
key will restart the dryer into the appropriate drying cycle. Once the dry cycle has started again, the HOT KEYS
will be enabled again.
Hot Keys Lock On Mode – In addition to the HOT KEY features described in the previous two (2) paragraphs,
the Phase 7 dual microprocessor controller (DMC) computer also has a HOT KEY feature that allows HOT KEY
Mode to be locked on.
In order to Lock On the Hot Key Mode, press and hold the desired HOT KEY, then toggle the program switch
up. This will lock the display onto the desired HOT KEY and the display will not be released until the program
switch is toggled back down. If another HOT KEY is desired simply press the desired HOT KEY and the display
will update to the new HOT KEY item. When in the HOT KEY Lock On Mode the Phase 7 DMC (computer)
will respond as normal, a cycle can be stopped, paused and started, however the display will remain displaying the
HOT KEY item and not the cycle information. This feature is intended for diagnostics and is not considered a
normal operating mode.
D. SCROLLING RATE
When in a menu item that has a numeric range, this feature will vary the scroll rate as you scroll through the
numeric range to help decrease the programming time. The “HI” and “LO” keys are used to increase and
decrease the values in a menu item. When increasing or decreasing a value in a menu item, if you hold the “HI”
or “LO” key for more than 3-seconds the scrolling rate will change to a faster rate.
E. PAUSE MODE
If the “PAUSE” key is pressed and the door is not opened, the dryer will restart in 20-seconds. If the
“PAUSE” key is pressed and the dryer door is opened and left open, the dryer will wait for the pause time
defined in PL #01 to expire. Once the pause time expires, the Phase 7 DMC (computer) will begin to count down
the dry time. If the dryer door is opened without first pressing the “PAUSE” key, the Phase 7 DMC
(computer) will continue to count down the dry time.
F. RPM
The Phase 7 DMC (computer) also displays the basket (tumbler) RPM by pressing and holding the “LO” key
while the basket (tumbler) is rotating (the basket [tumbler] must be rotating for approximately 30-seconds before
getting a true RPM reading). In Coin Mode, the program switch must be in the “UP” position.
