15
PAUSE TIME 0 TO 3 MINUTES
If the “PAUSE” key is pressed and the main door is open, the Phase 7 dual microprocessor controller (DMC)
computer will wait for the pause time defined in this setting to expire. Once the time has expired, the Phase 7
DMC (computer) will begin to count down the drying time. If the “PAUSE”
key is not pressed prior to
opening the door, the Phase 7 DMC (computer)
will not wait for the pause time before counting down the drying
time.
READY PROMPT
This option controls whether the Phase 7 DMC (computer) displays “READY” or “READY, INSERT $XX.XX
TO START”, when the Phase 7 DMC (computer) is in a READY state while in Coin Mode. The READY option
can be used when the dryer has a debit card system or central pay system implemented that is displaying its own
AMOUNT TO START. When this option is selected the Phase 7 DMC (computer) will remain displaying
“READY” until the AMOUNT TO START has been met, at this point the Phase 7 DMC (computer) will display
“SELECT TEMP TO START”. The “READY, INSERT AMOUNT TO START” option is used when the dryer
has its own coin acceptor installed and wishes to have the Phase 7 Dual Microprocessor Board display the
AMOUNT TO START. When in this option the Phase 7 DMC (computer) will display “READY, INSERT
$XX.XX TO START”. Once a coin is inserted, the Phase 7 DMC (computer) will display “ADD XX TO
START” until the AMOUNT TO START has been met, at which time the Phase 7 DMC (computer) will display
“SELECT TEMP TO START”.
PL #02 – MACHINE SETTINGS
SELECT MODEL
This location determines what type of dryer the Phase 7 DMC (computer) will be set up as. The six (6) possible
models are Gas Dual Motor, Electric Dual Motor, Steam Dual Motor, Gas Quad Motor, Electric Quad Motor and
Steam Quad Motor.
NOTE: In the event that the wrong model is selected, the Phase 7 DMC (computer) will go into a
model fault and will default to a Gas Dual Motor dryer.
SELECT ROTATION SENSOR MODE
This option controls whether the Phase 7 DMC (computer) should monitor the rotation of the basket (tumbler).
This program toggles ON/OFF.
ENTER LINT CLEANING FREQUENCY 0 TO 10 HOURS
This feature monitors the hours of drying time and compares it with the Lint Cleaning Frequency setting. Once
the Lint Cleaning Frequency time has been met, the Phase 7 DMC (computer) will begin prompting the user to
clean the lint drawer. The Phase 7 DMC (computer) will allow two (2) more hours of drying time before locking
out the Phase 7 DMC (computer). The Phase 7 DMC (computer) will not respond until after the lint drawer has
been cleaned out. When the lint drawer is opened, the display will read “LINT ACCESS OPEN”, and when the
lint drawer is closed, the Phase 7 DMC (computer) will go back to a READY state and will read “READY,
INSERT 25¢ TO START”.
