1-3
Getting Started
- 1 Line-In/Line-Out/Mic-In port
- 1 RJ-45 LAN connector
- 1 IEEE 1394 port (Optional)
- 1 CD-IN pin header
IEEE1394 (Optional)
h VIA VT6307 PCI Controller with integrated PHY (optional)
h Supports 2 1394 ports (Rear x1 / Front x 1)
Audio
h AC97 link controller integrated in ATI IXP 300.
h 6 channels S/W audio codec Realtek ALC655 codec
- Compliance with AC97 2.2 Spec
- Meets PC2001 audio performance requirement
h Supports SPDIF-Out pin header (Optional)
LAN (Optional)
h Realtek RTL8100C/8110SB
- Support 10Mb/s, 100Mb/s and 1000Mb/s (1000Mb/s only for 8110SB auto-nego-
tiation operation.
- Compliance with PCI 2.2 standard.
h Supports Wake-On-LAN and remote wake-up.
h Supports ACPI power management.
BIOS
h 4MB Award BIOS with PNP BIOS, ACPI, SMBIOS 2.3, Green and Boot Block.
h Provides DMI 2.0, WFM 2.0, WOL, WOR, chassis intrusion, and SMBus for system
management.
Dimension
h Micro-ATX Form Factor: 24.4 cm (L) x 24.4 cm (W).
Mounting
h 8 mounting holes.
Others
h Live BIOS/Live Driver Update
h PC2001 Compliant
h Suspends to RAM/Disk
MSI Reminds You...
The Windows 98 & Windows ME operating systems are not sup-
ported by this mainboard.
