© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Lint Filter
CLEAN THE LINT FILTER BEFORE DRYING
EACH LOAD. (Refer to Figure 33 for lint filter
location.) Cleaning the lint filter is important because
a layer or pad of lint on the filter will block the flow of
air through the dryer, thus reducing the efficiency of
the dryer. The clothes will take longer to dry and
energy will be wasted.
Figure 33
Dryer Motor Overload Protector
The motor overload protector stops the motor in the
event of an overload. After cooling, the overload
protector will reset itself. The dryer can be restarted by
pressing the start keypad. If the overload protector
cycles again, remove the unit from use and call the
service person to correct the problem.
SWD547N
1 Lint Filter
SWD547N
1
